Operating Instructions and Parts Manual
24503
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions
could result in personal injury and/or damage to product or property. Please retain instructions for future reference.
mULtIPUrPose DrILL
PowereD PUmP
For CUstomer servICe
Technical Question?
CALL 1-866-458-2472
customerservice@oem-tools.com
UNPACKING
After unpacking unit, inspect
carefully for any damage that
may have occurred during transit.
Check for loose, missing, or
damaged parts. If any damage
is observed, a shipping damage
claim must be filed with carrier.
Do not use Drill Powered Pump
if broken, bent, cracked or
damaged parts (including labels)
are noted. Any Drill Powered
Pump that appears damaged in
any way, operates abnormally or is
missing parts should be removed
from service immediately. If you
suspect that the Drill Powered
Pump was subjected to a shock
load (a load that was dropped
suddenly, unexpectedly, etc.)
immediately discontinue use until
it has been checked by a factory
authorized service center.
WARNING
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death.
03/14
2014 ©OEM-TOOLS
Advertisement
Table of Contents
Related Manuals for Oemtools 24503
Summary of Contents for Oemtools 24503
- Page 1 Operating Instructions and Parts Manual 24503 Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. Please retain instructions for future reference.
- Page 2 Instructions and Parts manual 24503 mULtIPUrPose DrILL PowereD PUmP Thank you very much for choosing an OEM-Tools 7. Don’t overreach. Keep proper footing and balance Product! at all times when operating this tool. 8. Check for damage. Check your tool regularly. If For future reference, please complete the owner’s...
- Page 3 Instructions and Parts manual 24503 mULtIPUrPose DrILL PowereD PUmP • Before use, read and understand all warnings, safety • The manufacturer declines any and all responsibility precautions, and instructions as outlined in the for damage to vehicles or components if said vehicle manufacturer’s service manual.
- Page 4 Instructions and Parts manual 24503 mULtIPUrPose DrILL PowereD PUmP ProDUCt sPeCIFICAtIoNs oPerAtING INstrUCtIoNs • Self Priming Always wear safety glasses WARNING • Delivery rate: without the inlet filter, delivery around and gloves! 40-50 liters/min (550-650 gallons/hour.)With the filter 1. Connect Drill Motor to Shaft.
- Page 5 Instructions and Parts manual 24503 mULtIPUrPose DrILL PowereD PUmP oem-tooLs™ YeAr LImIteD wArrANtY This warranty does not cover batteries, sensor tips or other materials that wear out during normal use. BEFORE RETURNING THE UNIT, PLEASE REPLACE OR CLEAN THE SENSOR TIP AND CHECK BATTERIES A spare tip is included with your Leak Detector.
