Model #: SU8000RT3UN50TF
SmartOnline 8kVA On-Line Double-Conversion UPS, 8U Rack/Tower, 208/120V NEMA outlets, 50A plug
Description
Tripp Lite SU8000RT3UN50TF 8000VA / 8kVA / 7200 watt online, double-conversion UPS system offers complete power protection for critical
network applications. This system delivers online, double-conversion UPS protection with zero transfer time, suitable for advanced networking
applications. Fault-tolerant auto-bypass prevents unexpected service interruptions during UPS overload or internal fault conditions. Included
detachable PDU with manual bypass switch enables hot-swappable replacement of entire UPS power module with no interruption to connected
equipment. Enhanced availability, fault tolerance and simple hot-swap replacement options make this UPS ideal for advanced networking
applications in data centers, computer rooms, network closets and rugged industrial locations.
Package Includes
SU8000RT3UPM 3U UPS power module
BP240V10RT3U external battery pack
SU5000XFMRT2U step down transformer
SUPDMB710 Detachable PDU with manual bypass switch
Four post compatible rack rail kit (3 sets)
Tower stands for upright tower configuration
PowerAlert software, complete data cabling and user manual
Features
Tripp Lite SU8000RT3UN50TF 8kVA / 8000VA / 7200 watt on-line, double-conversion UPS system in 8U total rack/tower configuration (3U
UPS power module, 3U external battery pack and 2U step-down transformer)
Detachable PDU with manual bypass switch enables hot-swappable UPS power module replacement with no interruption in output power to
connected networking equipment
Fault tolerant electronic bypass maintains utility output during a variety of UPS fault conditions
Hubbell CS8265 (208V 50A) or Hardwire input; 2 L6-30R, 4 L6-20R and 12 5-15/20R outlets
Maximum installed rack depth of only 32.5 in. / 82.6cm inches
Full-time active power conditioning provides clean, continuous dual-conversion AC output free of voltage fluctuations, power interruptions
and line noise
Double-conversion operation converts raw input from AC to DC, then resynthesizes output power back to perfect sine wave AC with
enhanced protection from harmonic distortion, fast electrical impulses and other hard-to-solve power problems not addressed by other UPS
types
Highlights
8kVA / 8000VA / 7200W on-line double-conversion UPS; 0.9 power factor
208/120V 60Hz output; Economy mode option
8U Rack/Tower configuration; Hot-swap power and battery modules
USB, RS232 & EPO ports; SNMP/WEB and contact-closure card options
Front panel LEDs with detailed LCD monitoring and control screen
Expandable runtime with optional external battery packs
Hubbell CS8265 input (3 wire); L6-30R, L6-20R & 5-15/20R outlets
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail:
saleshelp@tripplite.com
Advertisement
Related Manuals for Tripp Lite SmartOnline SU8000RT3UN50TF
Summary of Contents for Tripp Lite SmartOnline SU8000RT3UN50TF
- Page 1 SmartOnline 8kVA On-Line Double-Conversion UPS, 8U Rack/Tower, 208/120V NEMA outlets, 50A plug Description Tripp Lite SU8000RT3UN50TF 8000VA / 8kVA / 7200 watt online, double-conversion UPS system offers complete power protection for critical network applications. This system delivers online, double-conversion UPS protection with zero transfer time, suitable for advanced networking applications.
-
Page 2: Specifications
Expandable runtime is supported with optional BP240V10RT3U; BP240V557C-1PH; BP240V787C-1PH; BP240V1037C-1PH; BP240V1407C-1PH external battery packs Some external battery configurations require the use of Tripp Lite's Highly efficient operation in optional economy mode significantly reduces BTU heat output and operating energy costs... -
Page 3: Voltage Regulation
Output voltage +/- 2% regulation (line mode) Output voltage +/- 10% regulation (Economy line mode) Output voltage +/- 2% regulation (Battery mode) Built-in UPS output 12 5-15/20R outlet(s); 4 L6-20R outlet(s); 2 L6-30R outlet(s) receptacles Output circuit 20A double-pole (x2) protects 2 L6-20R outlets each, 30A double-pole (x2) protects 1 L6-30R outlets each, 20A breaker single-pole (x4) protect 3 5-15/20R outlets each Output AC waveform... - Page 4 Voltage regulation 2% output voltage regulation in standard online, double-conversion mode description Overvoltage Corrects overvoltages up to 300V correction Undervoltage Corrects undervoltages as low as 100V correction LEDS ALARMS & SWITCHES LED Indicators 6 LEDs indicate line power, online mode, economy/bypass mode, on-battery, charger and AC output status; LCD screen offers additional information and control options Front panel LCD Selectable LCD display with scroll and selection buttons enables UPS control and detailed monitoring options;...
- Page 5 Installed whole 32.5 system maximum rack depth (inches) Installed whole 82.6 system maximum rack depth (cm) Installed whole system total rack space height (rack spaces) Secondary form Tower factor UPS / Power Module weight (lbs) UPS / Power Module 19.5 weight (kg) Stepdown 3.5 x 17.5 x 20.8...
-
Page 6: Special Features
Cooling method ENVIRONMENTAL Operating +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius Temperature Range Storage +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius Temperature Range Relative Humidity 0 to 95%, non-condensing AC mode BTU / hr. 2732 (full load) AC economy mode... -
Page 7: Warranty
Description 3-Year Extended Warranty - For SU8000 models 5-Year Extended Warranty - For SU8000 models External battery pack for use with select Tripp Lite UPS Systems External Battery Pack and Cable. 3U, Expandable, Black 3-Point Connector External battery pack for use with select Tripp Lite UPS Systems... - Page 8 Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
