Model #: SU2200XLA
SmartOnline 2.2kVA On-Line Double-Conversion UPS, Tower, 110/120V NEMA outlets
Description
Tripp Lite's Smart Online SU2200XLa on-line, double conversion UPS protects critical server, networking or telecommunications equipment from
blackouts, brownouts, voltage fluctuations and surges in an attractive all-black upright tower form factor. Large capacity 2200VA/1600W UPS
continuously converts incoming AC to DC, then back to perfect sine wave AC output at 120V AC (+/-2%). Removes harmonic distortion, fast
electrical impulses, frequency fluctuations and other hard-to-solve power problems not addressed by other UPS systems. True sine wave output and
zero transfer time offers guaranteed compatibility with all equipment types. Includes 7 UPS supported outlets. 2 three-outlet load banks can be
independently controlled via software interface to selectively reboot remote equipment or automatically shed less critical loads to extend battery
runtime for the most critical equipment. Battery support can be extended with the addition of external battery packs. Includes slot for internal
SNMP/web card, plus DB9 enhanced serial monitoring port for unattended shutdown, remote control and monitoring of UPS system and power
data. Network management interfaces support simultaneous communications via USB port, DB9 serial port and SNMPWEBCARD slot.
HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Includes
Tripp Lite's PowerAlert UPS Power Management Software. Compatible with Tripp Lite's Watchdog Service Monitoring and Control Software.
Package Includes
SU2200XLa On-line Double-Conversion UPS System
PowerAlert Software and cabling
Instruction manual with warranty information
EPO (Emergency Power Off) cabling
Features
True on-line, double conversion UPS provides a constant, pure sine wave AC output
Maintains continuous operation through blackouts, brownouts, voltage fluctuations and surges with zero transfer time
Zero transfer time, on-line, double-conversion and economy-mode operation supported
Removes harmonic distortion, electrical impulses, frequency variations and other hard-to-solve power problems
Accepts input voltages between 80V and 150V (65V to 150V at loads under 70%), regulating output to 120V AC +/-2%
2200VA/1600W output capacity with 7 total outlets (6 NEMA5-15/20R and 1 L5-20R)
Two built-in individually switchable load banks, each with three outets, can be controlled via software interface to selectively reboot remote
equipment or automatically shed less critical loads to extend battery runtime for the most critical equipment
Standard internal battery set provides 14 min. runtime at half load and 4.5 min. at full load
Runtime is expandable with BP48V24-2U (limit 1) or BP48V60RT3U (multi-pack compatible) external battery packs
Highlights
2200VA / 2.2kVA / 1600 watt on-line double-conversion tower UPS
110/120V +/-2% output at 50/60Hz, high efficiency economy mode option
Expandable runtime, Hot-swappable battery modules
USB, RS232 & EPO ports; support for SNMP/WEB card options
Front panel status LEDs with detailed load and battery metering
2 independently switchable output load banks
NEMA 5-20P input; L5-20R & 5-15/20R outlets
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail:
saleshelp@tripplite.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SmartOnline SU2200XLA and is the answer not in the manual?

Questions and answers

Summary of Contents for Tripp Lite SmartOnline SU2200XLA

  • Page 1 SmartOnline 2.2kVA On-Line Double-Conversion UPS, Tower, 110/120V NEMA outlets Description Tripp Lite's Smart Online SU2200XLa on-line, double conversion UPS protects critical server, networking or telecommunications equipment from blackouts, brownouts, voltage fluctuations and surges in an attractive all-black upright tower form factor. Large capacity 2200VA/1600W UPS continuously converts incoming AC to DC, then back to perfect sine wave AC output at 120V AC (+/-2%).
  • Page 2: Specifications

    Included PowerAlert UPS Power Management Software and cabling provides monitoring of in-depth site power conditions, full UPS status and fault warnings, output load level and load bank power control Compatible with Tripp Lite's WatchDog Service Monitoring and Control Software (part# WATCHDOGSW) Fault tolerant electronic bypass maintains utility output during a variety of UPS fault conditions...
  • Page 3: Voltage Regulation

    Rated input current (at 16A (120V), 17.6A (110V) maximum load) Nominal Input 110V AC; 120V AC Voltage(s) Supported UPS input connection 5-20P type Input circuit breaker UPS Input cord length (ft.) UPS Input cord length Recommended 20A 120V Electrical Service BATTERY Full load runtime 4.5 min.
  • Page 4 Switches 2 switches control off/on power status and alarm-cancel/self-test operation SURGE / NOISE SUPPRESSION UPS AC suppression joule rating UPS AC suppression Instantaneous response time UPS Dataline 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet suppression EMI / RFI AC noise suppression PHYSICAL Installation form...
  • Page 5: Warranty

    Battery mode BTU / hr. 885.6 (full load) AC economy mode efficiency rating (100% load) Audible Noise < 45 dB at front side 1m COMMUNICATIONS Communications USB (HID enabled); DB9 Serial; Contact closure; EPO (emergency power off); Slot for SNMP/Web interface interface Network monitoring Supports detailed monitoring of UPS and site power conditions;...
  • Page 6 Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
