Tripp Lite SmartOnline SU10K Owner's Manual

6/10kva on-line, extended-run ups systems
Hide thumbs Also See for SmartOnline SU10K:
Table of Contents

Advertisement

Quick Links

Download this manual
1111 W. 35th Street
Chicago, IL 60609 USA
Customer Support: (773) 869-1234
Application Services: (773) 869-1236
www.tripplite.com
Safety:
Control Panels:
Installation:
Operation:
Communications:
Service:
Warranty & Insurance:

Function Block Diagram:

Specifications:

Copyright © 2001 Tripp Lite. All rights reserved. SmartOnline
Owner's Manual
SmartOnline
• SU6K (6kVA)
• SU10K (10kVA)
On-Line, Extended-Run UPS Systems
ESPAÑOL: p. 18
FRANÇAIS: p. 35
p. 2
p. 3 - 5
p. 9 - 12
p. 13 - 14
p. 15
p. 15
p. 16
p. 17
TM
is a registered trademark of Tripp Lite.
TM
p. 6 - 9
1

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite SmartOnline SU10K

Summary of Contents for Tripp Lite SmartOnline SU10K

  • Page 1: Function Block Diagram

    Control Panels: Installation: Operation: Communications: Service: Warranty & Insurance: Function Block Diagram: Specifications: Copyright © 2001 Tripp Lite. All rights reserved. SmartOnline Owner's Manual SmartOnline • SU6K (6kVA) • SU10K (10kVA) On-Line, Extended-Run UPS Systems ESPAÑOL: p. 18 FRANÇAIS: p. 35 p.
  • Page 2 It also must be suitably grounded. Equipment Connection Warnings • Do not use Tripp Lite UPS Systems in life support applications in which a mal- function or failure of a Tripp Lite UPS System could cause failure or significantly alter the performance of a life support device.

  • Page 3: Control Panels

    Control Panels Familiarize yourself with the location and function of the front and rear panel features before installing and operating your UPS. FRONT PANEL 1. “ON/OFF” Switch: This momentary rocker switch turns the UPS System’s inverter ON and OFF. 2. “SELECT” Button: This button performs two functions: it allows you to browse through different power readings on the LCD Display by momentarily pressing the button;...

  • Page 4: Rear Panels

    Rear Panels SU10KBP SUBP ON LINE MODE ECONOMY MODE SU10KPM ON LINE MODE ECONOMY MODE L1 L2 SU6K...
  • Page 5 8. “Smart” RS-232 Interface Port: This female DB9 port connects your UPS to a workstation or server. It uses RS-232 communications to report UPS and power conditions. It is used with Tripp Lite software and the included RS-232 Cable to monitor and manage network power and to automatically save open files and shut down equipment during a blackout.

  • Page 6: Installation

    Installation INVERTER OPERATION DIP SWITCH SETTINGS (SU10KPM SHOWN) Using a small tool, set the four Inverter Opera- tion DIP Switches (located on the rear panel of your UPS, see pg. 4-5 for location) to match your input voltage, input frequency and desired operational mode.

  • Page 7: Ups Location

    UPS LOCATION Move your UPS over short distances using its wheels. Stabilize the UPS by releasing the stabilizers on each side of the unit. NOTE: Do not stack the UPS Systems or external battery packs. INPUT AND OUTPUT CONNECTION WIRING SELECTION Choose appropriate cabling (depending on current carried;...

  • Page 8: External Battery Pack Connection

    UPS. SUBP Note: Optional Tripp Lite external battery packs (SUBP's) feature individual 120V AC input line cords and individual internal battery chargers. By adding multiple SUBP's individually connected to 120V AC input, the recharge time of a battery system will be dramatically reduced as compared to systems relying on only the UPS's main charger.

  • Page 9: Operation (Normal Conditions)

    BATTERY CONDITION VERIFICATION When the UPS is operating from battery power, the alarm and LCD Display will both alert you to the UPS battery’s charge condition. Battery Charge Condition FULL UNDER INITIAL BATTERY CHARGING (OPTIONAL) Your UPS System’s battery is fully charged prior to shipping. However, if your UPS has been stored for an extended period, recharge its battery for 8 hours.

  • Page 10: Self-Testing

    SELF-TESTING When you turn the UPS ON, it will perform a brief (about 25 second) self-test. See figure below for display sequence.* *Note: If starting from battery, the BATTERY LED will be lit and the I/P and BYPASS LEDs will not. The final LCD display in the diagram below appears when the UPS is operating normally under utility-supplied AC input power.

  • Page 11: Operation (Special Conditions)

    LCD DISPLAY SELECT SWITCH Momentarily press the “SELECT” switch on the front panel to browse through different power readings on the LCD Display. The LCD Display will show which one of four operational modes your UPS is currently in: Normal, Economy, On-Battery, or Bypass. Also, as you press the “SELECT”...

  • Page 12: Operation Under Shutdown

    BATTERY CHARGE WARNINGS Since your UPS can provide battery backup only for as long as the batteries remain charged, these warnings should be acted on immediately. Battery Charge Warning Battery charge nearly depleted AC/DC charger not operating OPERATION UNDER SHUTDOWN Your UPS will shut down and the LCD will display a message if it detects one of the following conditions.
  • Page 13 This female DB9 port connects your UPS via an RS-232 cable to a workstation or server equipped with Tripp Lite software. The port uses RS-232 communications to report UPS status and power conditions. Using this port, Tripp Lite software can monitor and manage network power and automatically save open files and shut down equipment during a blackout.

  • Page 14: Dry Contact Interface

    DRY CONTACT INTERFACE: This female DB9 contact-closure port allows your UPS to send contact-closure signals to indicate that it is on battery back-up mode and if its batteries are running low. The port can also receive a remote shutdown signal. Pin assignment: DRY CONTACT INTERFACE TABLE UPS Operating...

  • Page 15: Warranty & Insurance

    10 days of purchase. The warranties of all TRIPP LITE surge suppressors are null and void if they have been connected to the output of any UPS system. The warranties of all TRIPP LITE UPS Systems are null and void if a surge suppressor has been connected to its output receptacles.

  • Page 17: Specifications

    Specifications (Note: Excluding isolation transformer) Model Input Input Voltage Input Frequency Input Current Inrush Current Power Factor (Full Load) Efficiency (Full Load/On-Line) Circuit Breaker Output Watts (Power Factor: 0.7) Waveform (On-Line) Waveform (On-Battery) Output Voltage (RMS) Output Frequency Voltage Regulation Max.
