Equipment Connection Warnings • Do not use Tripp Lite UPS Systems for life support applications in which a malfunction or failure of a Tripp Lite UPS System could cause failure or significantly alter the performance of a life-support device.
UPS, plug your equipment into the UPS.* * Order additional jumper cords from Tripp Lite. Call (773) 869-1234; order part # P004-006. Your UPS is designed to support only com- puter equipment. You will overload the UPS if the total VA ratings for all the equipment you connect exceeds the UPS's Output Capacity (see Specifications).
DB9 port of your computer to the DB9 port of your UPS. Install on your computer the Tripp Lite PowerAlert Software appropriate to your computer’s operating system. Your UPS may feature additional communications ports;...
Optional Installation EPO Port Connection This optional feature is only for those applica- tions which require connection to a facility’s Emergency Power Off (EPO) circuit. When the UPS is connected to this circuit, it enables emer- gency shutdown of the UPS's inverter. Using the cable provided, connect the EPO port of your UPS (see ) to a user-supplied normally...
Page 6
UPS batteries need to be recharged or replaced. Allow the UPS to recharge continuously for 12 hours, and repeat the self-test. If the LED remains lit, contact Tripp Lite for service. If your UPS requires battery replacement, visit www.tripplite.com to locate the specific Tripp Lite replacement bat-...
Page 7
Allow the UPS to recharge continuously for 12 hours, and repeat the self-test. If the LED continues to light, contact Tripp Lite for service. If your UPS requires battery replacement, visit www.tripplite.com to locate the specific Tripp Lite replacement...
Page 8
IEC320-C13 (female) or USB connection to your UPS, you can remotely reboot connected equipment by turning the receptacles OFF and ON using Tripp Lite’s PowerAlert Software. Select models have their receptacles divided into one or more load banks (labeled “LOAD 1,” etc.) which may...
Page 9
UPS. Refer to your accessory’s manual for installation instructions. Contact Tripp Lite Customer Support at (773) 869-1234 for more infor- mation, including a list of available SNMP, networking management and connectivity products.
AC Noise Attenuation (>40 dB at 1MHz); AC Protection Modes (H to N, H to G, N to G). “+” Battery runtime can be extended with addition of optional Tripp Lite External Battery Pack (sold separately). SMARTINT3000VS uses BP48V18 battery pack. External battery will increase both the battery runtime and the battery recharge time.
