Intelligent, Line-Interactive UPS System
• 120V/230V Auto-Sensing Input, 120V Output
Owner's Manual
SMART700DV
Not suitable for mobile applications.
1111 W. 35th Street, Chicago, IL 60609 USA
Customer Support: (773) 869-1234 • www.tripplite.com
Copyright ©2006 Tripp Lite. All rights reserved.
2
3
4
5
8
9
10
10
Advertisement
Related Manuals for Tripp Lite SMART700DV
Summary of Contents for Tripp Lite SMART700DV
-
Page 1: Table Of Contents
Quick Installation Optional Installation Basic Operation Storage and Service Battery Replacement Specifications Warranty Registration 1111 W. 35th Street, Chicago, IL 60609 USA Customer Support: (773) 869-1234 • www.tripplite.com Not suitable for mobile applications. Copyright ©2006 Tripp Lite. All rights reserved. -
Page 2: Important Safety Instructions
SAVE THESE INSTRUCTIONS This manual contains important instructions that should be followed during the installation, operation and storage of all Tripp Lite UPS Systems. Failure to heed these warnings will void your warranty. UPS Location Warnings • The UPS is heavy. Use caution when lifting it. -
Page 3: Quick Installation
Quick Installation Plug the UPS into a wall outlet supplying either 120V or 230V (nominal) AC power. Use the included detachable power cord. The IEC-320 end connects to the AC input receptacle on the rear of the UPS; the NEMA 5-15 end connects to the wall outlet. -
Page 4: Optional Installation
(see ) to connect the communication port on your equipment to the communication port of your UPS. Install on your equipment the Tripp Lite PowerAlert Software appropriate to your equipment’s operating system. Consult your PowerAlert manual for more information. -
Page 5: Basic Operation
UPS batteries need to be recharged or replaced. Allow the UPS to recharge continuously for 12 hours, and repeat the self-test. If the LED remains lit, contact Tripp Lite for service. If your UPS requires battery replacement, visit www.tripplite.com to locate the specific Tripp Lite replacement battery for your UPS. - Page 6 UPS batteries need to be recharged or replaced. Allow the UPS to recharge continuously for 12 hours, and repeat the self-test. If the LED contin- ues to light, contact Tripp Lite for service. If your UPS requires battery replace- ment, visit www.tripplite.com to locate the specific Tripp Lite replacement bat-...
- Page 7 NEMA 5-15R Communications Ports (USB or RS-232): These ports connect your UPS to any workstation or server. Use with Tripp Lite’s PowerAlert Software and included cables to enable your computer to automatically save open files and shut down equipment during a blackout. Also use PowerAlert Software to monitor a wide variety of AC line power and UPS operating conditions.
-
Page 8: Storage And Service
2. If the problem continues, do not contact or return the UPS to the dealer. Instead, call Tripp Lite at (773) 869-1233. A service technician will ask for the UPS's model number, serial number and purchase date and will attempt to correct the problem over the phone. -
Page 9: Battery Replacement
Battery Replacement Under normal conditions, the original batteries in your UPS will last many years. See Safety section before replacing batteries. The batteries are designed for hot-swap replacement (i.e. leaving the UPS in ON mode), but some qualified service personnel may wish to put the UPS in the OFF mode and disconnect equipment before proceeding. -
Page 10: Specifications
Regulatory Compliance Identification Numbers For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique series number. The series number can be found on the product nameplate label, along with all required approval markings and information. - Page 12 1111 W. 35th Street Chicago, IL 60609 USA Customer Support: (773) 869-1234 • www.tripplite.com 200511135 93-2513...
