Tripp Lite SM2200RMNAFTA Specifications

Model #: SM2200RMNAFTA
Smart Pro Line Interactive 2U Rack/Tower Extended Run UPS - NAFTA assembled version of
SMART2200RMXL2U
Description
2200VA line interactive UPS system for server, network and telecommunications equipment. 2U rackmount or tower form factor with an installed
depth of only 19 inches. Expandable battery runtime with optional BP48V24-2U and BP48V60RT-3U external battery packs. Uninterruptible Power
Supply (UPS) switches to battery-derived AC output during power failures and extreme voltage variations. Line interactive Automatic Voltage
Regulation (AVR) offers two levels of voltage boost during brownouts and one level of voltage cut during overvoltages to maintain regulated 100,
110, 120v selectable output over an input range of 83-145V. Includes NEMA 5-20P input plug (with NEMA 5-15P plug option) and both NEMA
5-15R and 5-15/20R output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support simultaneous
communications via USB port, DB9 serial port and SNMPWEBCARD slot. HID-compliant USB interface enables full integration with built-in power
management and auto shutdown features of Windows and Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test
data and utility power conditions via all 3 network interfaces. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off
(EPO) interface. Integrated 3-bank PDU switching supports load shedding and remote-reboot of connected equipment. 3-stage metered current
monitoring and battery charge status LEDs. Utility power and voltage regulation LEDs. Audible alarm. Self-test. 4-post rackmount accessories
included; 2-9USTAND tower kit and 2POSTRMKITWM two post rack & wallmount accessories available. Field-replaceable, hot-swappable internal
batteries and external battery packs. Attractive all-black color scheme. $250,000 connected equipment insurance;
Package Includes
SM2200RMNAFTA UPS system
PowerAlert software CD-ROM
USB, serial and EPO cabling
Owner's manual with warranty information
Features
SmartPro line interactive UPS system is ideal for voice, data, medical and industrial networking applications
Line interactive Automatic Voltage Regulation (AVR) offers two levels of voltage boost during brownouts and one level of voltage cut during
overvoltages
Highlights
2200VA / 2.2kVA line interactive, extended-run 2U rack / tower UPS
Maintains sine-wave 100/110/120V nominal output over an input range of 83
to 145V
Network communications supported via HID enabled USB port, DB9 serial
port, SNMP/Web card slot and EPO interface
Current monitoring and switched PDU control via 3 individually controllable
load banks
Input: NEMA 5-20P (120V 20A / includes 5-15P plug 120V 15A) / Output: 4
NEMA 5-15/20R, 4 NEMA 5-15R (120V)
$250,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only)
