Tripp Lite SM2200NAFTA Specification Sheet

Model #: SM2200NAFTA
Smart Pro line interactive UPS System - NAFTA assembled version of SMART2200NET
Description
Tripp Lite's SM2200NAFTA intelligent, line interactive large tower UPS system protects servers, networking accessories and telecommunications
equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 27 minutes half load runtime and 11 minutes fully
loaded. Runtime is expandable with optional BP24V28-2U (limit 1) and BP24V70-3U external battery packs. 2200VA/1700 watt power handling
capability supports a variety of networking, telecom and other sensitive electronic applications. Includes 6 protected outlets. Supports remote
monitoring of UPS and site power conditions via built-in RS-232 enabled monitoring port, plus standard UPS monitoring via 2 built in contact closure
ports. Includes PowerAlert UPS monitoring and unattended shutdown software with complete cabling. Built-in audible alarm and front panel LEDs
indicate line power, battery power, battery charge level, load level, plus voltage regulation status. Network grade AC surge suppression protects
equipment from damage and performance problems resulting from transient surges. Attractive large gray tower housing. $250,000
equipment insurance.
Package Includes
SM2200NAFTA UPS System
PowerAlert Software and three 6 foot network cables
Warranty information
Instruction manual
Features
SM2200NAFTA line interactive UPS offers battery derived AC output during power outages, voltage regulation during brownouts and
overvoltages, plus network-grade AC surge suppression
2200VA/1700 watt power handling capability supports a variety of networking, telecom and other sensitive electronic devices
Large internal batteries offer runtimes of 27 minutes at half load (1100VA/850 watts) and 11 minutes at full load (2200VA/1700 watts)
Runtime is further expandable with optional external BP24V28-2U (limit 1) and BP24V70-3U (multi-pack compatible) battery packs
Automatic Voltage Regulation (AVR) circuits maintain 120V nominal output over an input voltage range of 87-140V
Includes 6 fully protected NEMA 5-15R outlets with 2 single outlet load banks that can be individually powered off and back on again via
software interface
PowerAlert UPS monitoring and unattended shutdown software enables configurable network broadcast messaging, email notification,
event logging and running user defined script commands
Offers simultaneous monitoring of up to 3 directly connected devices through included DB9 contact closure and RS-232 enabled interfaces,
or the monitoring of any number of additional servers over IP with included PowerAlert monitoring software
Highlights
2200VA / 2.2kVA line interactive, extended-run tower UPS
Maintains 120V nominal output over an input range of 87 to 140V
Network communications supported via 3 DB9 ports (1 serial / 2 contact
closure)
Input: NEMA 5-15P (120V 15A) / Output: 6 NEMA 5-15R (120V)
$250,000 Ultimate Lifetime Insurance
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: saleshelp@tripplite.com
(USA, Puerto Rico and Canada only)
