Tripp Lite SM1500NAFTA Specification Sheet

Model #: SM1500NAFTA
Smart Pro Line Interactive Tower UPS System - NAFTA assembled version of the SMART1500
Description
Tripp Lite's SM1500NAFTA intelligent, line interactive UPS system protects servers, networking accessories and telecommunications equipment
from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 20 minutes half load runtime and 7 minutes at full load during
power failures. 1500VA/980 watt power handling capability supports a variety of networking, telecom and various other application types, including
the support of multiple network workstations. Includes a total of 6 outlets, 1 of which can be individually powered on and off via software interface to
selectively reboot remote equipment or to automatically shed less significant loads to extend battery runtime for more critical equipment. Supports
remote monitoring of UPS and site power conditions via built-in USB and DB9 monitoring ports. Includes PowerAlert UPS monitoring and
unattended shutdown software with complete cabling. Supports SNMP with optional SNMPWEBSOLO external adapter. Built-in audible alarm and 5
front panel LEDs indicate status of line power, battery power, battery low/replace, voltage regulation and load level. Wall mountable with optional
UPSWM wallmount bracket. Network-grade AC surge suppression protects equipment from damage and performance problems resulting from
transient surges. Attractive, small-footprint tower housing uses less than 66 square inches of floor or desktop space. $250,000
insurance (USA and Canada Only).
Package Includes
SM1500NAFTA UPS System
USB and DB9 monitoring cables
PowerAlert unattended shutdown and UPS/Power monitoring software
Instruction manual with warranty information
Features
1500VA/980 watt power handling capability supports a variety of networking, telecom and various other application types
Built-in voltage regulation and battery support, plus complete AC suppression prevents equipment damage, data loss and downtime
Large internal batteries offer 20 minutes half load runtime and 7 minutes at full load during power failures
Automatic Voltage Regulation (AVR) circuits with two boost and one voltage reduction level maintains usable 120V nominal output over an
input voltage range of 75-147V
Includes a total of 6 NEMA5-15R outlets, 1 of which can be individually powered on and off via software interface to selectively reboot
remote equipment or shed less significant loads to extend battery runtime for more critical equipment
Includes 1 USB and 1 DB9 monitoring port for remote monitoring of UPS status and site power conditions
Communications ports enable safe unattended shutdown without data loss during extended power failures
Communications ports support messaging of UPS and line power status, including on-battery, low-battery, power-restored, AC line voltage,
Highlights
1500VA / 1.5kVA line interactive tower UPS
Maintains 120V nominal output over an input range of 75 to 147V
Network communications supported via USB port, serial port
Input: NEMA 5-15P (120V 15A) / Output: 6 NEMA 5-15R (120V)
$250,000 Ultimate Lifetime Insurance
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: saleshelp@tripplite.com
(USA, Puerto Rico and Canada only)
connected equipment
Tripp Lite
