IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
A.
Top
1 pc.
B.
Front Rail
1 pc.
F.
Door
1 pc.
For assembly see instructions in carton 88 5518 652
C.
Side Panel
1 pc.
H.
Back Rail
2 pcs.
G.
Door
1 pc.
D.
Side Panel
1 pc.
I.
Back Panel
2 pcs.
E.
Shelf
2 pcs.
J.
Back Post
1 pc.
