Tripp Lite APSX1250F Specification Sheet

Model #: APSX1250F
PowerVerter APS X Series Inverter/Charger - with Faster Auto-Transfer Switching

Description

Tripp Lite's APSX1250F DC-to-AC inverter with faster automatic line-to-battery transfer and integrated charging system serves as an extended-run
UPS, a stand-alone power source or an automotive inverter. Supplies up to 1250W of continuous 230V AC power to 2 AC outlets from any 12V
battery or automotive DC source. OverPower inverter output feature temporarily provides up to 150% of the continuous output for up to 1-60 minutes
and DoubleBoost inverter output feature delivers up to 200% of the continuous output for up to 10 seconds, providing the extra power needed to cold
start heavy-duty tools and motorized equipment. When AC cable is connected to a live wall socket, commercial power passes through to connected
equipment and the battery set is recharged via a 3-stage selectable 7.5/30A charging system. In UPS mode, the APS system responds to blackouts
and voltage fluctuations with near-instantaneous automatic transfer to battery-derived AC output. Includes a set of high-current DC input terminals
for simple installation (user supplies batteries and cabling—see owner's manual for recommendations). Passes sine wave utility or generator power
during battery charging and UPS line power operation, and efficient PWM sine wave AC output in inverter and UPS backup modes. Reliable large
transformer design with frequency control powers resistive electronic loads or large inductive motors, compressors and other items with high current
needs on startup. Optional APSRM4 wired remote power switch with full status LEDs provides remote power inverter on/off switching and continuous
status information (APSRM4 sold separately). Provides unlimited runtime with connection of any number of user-supplied batteries. Highly adaptable
to a variety of applications and site conditions with adjustable charger settings for wet/gel battery types and selectable line-to-battery power transfer
voltages.

Applications

Versatile inverter/charger system with auto-transfer switching serves as an automotive inverter for RVs, over-the-road trucking, conversion
vans, marine environments and fleet service vehicles; a standalone alternative power source for off-grid alternative energy or export
applications, and as an uninterruptible power supply (UPS) for items compatible with a 10-millisecond transfer time.

Package Includes

APSX1250F Inverter/Charger
Instruction manual with warranty information
(1) Universal Receptacle Adapter compatible with multiple international plug sets

Features

Comparable to the APSX1250 with faster auto-transfer switching
Supports 230V AC output from a 230V AC line power source or 12V DC battery source

Highlights

12V DC or 230V AC input; 230V, 50 Hz output; 2 AC outlets
1250W continuous, 1875W OverPower and 2500W DoubleBoost inverter
output (see specifications)
3-stage selectable 7.5 / 30 amp wet/dry cell battery charger
Faster Auto Transfer Switching option for battery backup/UPS operation
Reliability-enhanced large-transformer design with protected DC terminals
