Tripp Lite PDU1230 Specification Sheet

Model #: PDU1230
Single-Phase Basic PDU, 30A 208/240V, 1U Horizontal Rackmount, C13 & C19 outlets, NEMA L6-30P input plug
Description
Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution. Supplies equipment with continuous power from
any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation
with included mounting accessories.
Applications
Multi-outlet power distribution unit is the ideal means of powering multiple loads in 19-inch rackmount, wallmount and under-counter
applications, such as internetworking, PC systems, telecommunications, audio/video, security, sound reinforcement and more. Ideal for
distribution of UPS, generator or commercially derived AC power to protected equipment.
Package Includes
PDU1230 Power Strip
Warranty information
Instruction manual
Features
30A single phase 208/240V Basic Power Distribution Unit / PDU
Attached NEMA L6-30P 30A 208/240V input plug with 15 ft. / 4.5m line cord
1U horizontal rackmount format installs in one rack space
20 outlets (4 C19, 4 C13 front / 12 C13 rear)
Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats
Back panel grounding lug
Specifications
OVERVIEW
Model Type
PDU Type
OUTPUT
Frequency compatibility
Highlights
Basic
Basic
50 / 60 Hz
Basic single phase 30A 208/240V PDU
1U horizontal rackmount installation
NEMA L6-30P input; 15 ft. / 4.5m line cord
20 outlets (4 C19, 4 C13 front / 12 C13 rear)
Reversible housing; 5.2 in. / 13.2 cm depth
