FILA FILActive 38-104 Series User Manual

FILActive
38-104
www.fila.com/watch
1
Design of the Watch
Thank you for purchasing this watch.
Please read this manual thoroughly before using the watch!
Stopwatch
1/20 Sec. Dial
Hour
Hand
Small
Second Hand
Stopwatch
Second Hand
Stopwatch
Hour Dial
2
Specifications
• Time Module YM9G
• Chronograph with date
• Stainless steel case
• Solid stainless steel bracelet
• 10 ATM
* These specifications might be changed without prior notice.
3
Date and Time Setting
N 1
1. - 2.
1. Pull out the crown to the position 1.
2. Turn the crown clockwise to adjust the date.
3. Pull out the crown to the position 2 when the second hand is
at the 12 o'clock position. It will stop on the spot and rotate
the hour and minute hands by turning the crown.
- Turn clockwise to advance the hour and minute hands past
12:00a.m. Doing so will advance the date to the current date.
- Set the hour and minute hands to the desired time taking
AM or PM into consideration.
4. Push the crown back in to the normal position in accordance
with a time signal.
NOTE
- When setting the minute hand, first advance it 4 to 5 minutes
ahead of the desired time and then turn it back to the exact
minute.
- Do not set the date between 9:00p.m. and 1:00a.m.
Otherwise, it may not turn properly. If it is necessary to set the
date during that time period, change the time to any time
outside it, set the date and then reset the correct time.
- All stopwatch dials and hands will automatically reset to "0", if
the crown is pulled out to the position 2.
User
MANUAL
FM-749.1
Minute
Hand
Stopwatch
Start /Stop
[A]
Date
N 1
Stopwatch
Split /Reset
[B]
N: Normal
1: Adjust date
Stopwatch
2: Adjust hands
Minute Hand
3.
4
Using the Stopwatch
Standard Measurement
1. Press [A] to start counting, press [A] to stop counting.
2. Press [B] to reset the stopwatch.
The stopwatch can measure up to 11:59' 59" 95 in 1/20 second
increments. When the measurement reaches 12 hours, the
stopwatch automatically stops counting.
Accumulated Elapsed Time Measurement
Time 1 + Time 2 = Accumulated Elapsed Time
1. Press [A] to start counting, press [A] to stop counting.
2. Press [A] to start continuously counting.
2
3. Press [A] to stop and review the accumulated elapsed time.
4. Press [B] to reset.
Note: Restart and stop the stopwatch can be repeated as many
times as necessary by pressing [A].
Split Time Measurement
1. Press [A] to Start counting, press [B] to take the split time /
release split.
2. Press [A] to Stop counting.
3. Press [B] to reset.
Note: Measurement and release of the split time can be
repeated as many times as necessary by pressing [B].
Measurement of Two Competitors
N 1 2
1. Press [A] to start counting.
2. Press [B] when 1st Competitor finish.
3. Press [A] when 2nd Competitor finish.
4. Press [B] to review the finish time of 2nd Competitor.
5. Press [B] to reset.
Start Stop
[A] [A]
N
Start Stop
[A] [A] [A] [A]
Start
[A] [A]
Time 1
N
Time 2
Start
[A]
Split/
Split release
N
[B]
Start
Stop
[A] [B]
Finish time of
1st Competitor
1st Competitor
N
2nd Competitor
Reset
[B]
Stop
[A] [A]
Reset
[B]
Stop
[A]
Reset
[B]
Stop
Press
[A] [A]
[B]
Finish time
of 2nd
Competitor
