Tripp Lite N816-05M Specification Sheet

Model #: N816-05M
5M (16-ft.) 10Gb Duplex MMF 50/125 OM3 LSZH Patch Cable (LC/SC) - Aqua
Description
Tripp Lite introduces it's new OM3 Laser-Optimized Multimode Fiber (LOMMF) "Aqua" cables, for use with 10Gb Ethernet applications. These new
technology, 50/125um, SC/LC Fiber Optic cables, provide nearly three times the bandwidth over conventional 62.5um multimode fiber, with
performance rivaling that of Singlemode cable, at a much reduced cost. LOMMF cable allows 10Gb serial transmission over extended distances in
the 850nm wavelength window, where low-cost Vertical Cavity Surface Emitting Lasers (VCSELs) enable a cost-effective, high-bandwidth solution.
LOMMF is ideally suited for LAN's, SAN's, and high-speed parallel interconnects for head-ends, central offices, and data centers.
Applications
For use with 10-Gigabit Ethernet equipment
Package Includes
5 meter Duplex Multimode 50/125 Aqua OM3 Fiber Patch Cable, SC/LC
Features
10gb Ethernet speed to 300 meters @850nm, OM3 Rated
Use with VCSEL and LED laser light sources
High-Speed, High-Bandwidth, Low-Cost
Backward compatible with legacy LAN's
Ideal for Fibre Channel (SAN) applications
IEEE 802.3ae and TIA LOMMF compliant
Specifications
OVERVIEW
Clad Diameter
Core Diameter
Fiber Type
Number of Fibers
Intended Application
Highlights
125um
50um
50/125 LOMMF
2
Computer Networking (Fiber)
Designed for 10-Gig Ethernet applications...OM3 Rated
Backward compatible with existing 50/125 fiber
Max 10Gb distance of 300 meters @850nm
Low-Smoke, Zero Halogen (LSZH) Aqua jacket
