- Page 1 Assembly Instruction 2 PERSON ASSEMBLY 4654 bestchoiceproducts P1/ 8...
- Page 2 4 x1PC 1 x1PC 2 x1PCS 3 x1PCS 8 x2PCS 6 x1PC 5 x1PC 7 x1PC 9 x1PC 12 x 13 x 14 x1PC x1PCS x1PCS M6x12mm 15 x1PC 16 x1PC 17 x5PCS 18 x5PCS Ax20PCS 15x12mm 8x30mm M4x35mm M6x35mm M3.5x12mm Cx24PCS Bx24PCS...
- Page 3 Step 1 Step 2 Attach slider railings to shelf sides with part F screws. Attach shelf sides to shelf with cam bolts, cam locks, and dowels. P3/8...
- Page 4 Step 3 Attach shelf and sides to bottom with cam bolts, cam locks, and dowels. Attach part L bracket with part F screws. Slide in the L1 stopper Step 4 Slide in backs. P4/8...
- Page 5 Step 5 Attach two part brackets with part F screws.Slide in tow L1 stoppers. Attach top with cam bolts, cam locks,and dowels Step 6 Attach feet frame to feet with part E screws Attach feet with part A screws. P5/8...
- Page 6 Step 7 Attach part K hinges and doors with part F screws. Attach two L2 metal pieces. Screw A Screw B Screw C IMPORTANT:IF DOOR NOT ALIGNED Screw A:You can adjust the doors up and down by releasing screw A. Screw B:Release Screw B you can move the door forward or back till it is in the right position, then fully screw them.
- Page 7 Step 9 Attach slider railings to the drawer. Step 10 Insert the drawer. If the drawers are not aligned or overlap each other, then unscrew runner’s screws slightly, re-adjust the drawers so they are fully aligned and levelled,then fully screw in the runner’s screws. P7/8...
- Page 8 Step 11 P8/8...
