Bourne
Recommended Tools
Screw Gun
#2 & #3 Phillips Head Bit
#2 & #3 Phillips Screw Driver
Package Contents
Top
Apron
Step 1
Position Apron in Place on Top
• Flip top upside down and lay on a flat
smooth surface.
• Position Apron in the center of the
Top as shown.
• DO NOT fasten to the Top at this point.
Apron
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
Socket
Wrench
Legs
(Qty. 4)
jsifurniture.com
812.482.3204
800.457.4511
812.482.1548
1
" Socket
/
2
Level
Hardware Used
#10 x 1 " Flat Head Screws
Lock
Washers
Step 2
Position Legs in Place
• Slide all Legs into corners of apron. Bolt heads
on Legs will fit into cutouts and rest flush onto
the Top as shown.
225 Clay Street / PO Box 231
O
Jasper, Indiana 47546
F
Installation Instructions
Wood Table Assembly
" Pan Head Screws
3
#8 x 1
/
4
#10 x 3 " Truss Head Screws
5/16-18 x 2
1
" Hex Bolt
/
2
Washers
Legs
Page 1 of 2
Form No. INST-BU001
5/1/16
