Hyundai C2017 ADU01 Manual

- Accessory Installation
Instructional Symbols / Definitions
Denotes warnings that may lead to
serious physical injury or vehicle
damage.
Denotes cautions to be taken to avoid
physical injury or electronic component
damage.
Denotes cautions to be taken to avoid
vehicle and component damage.
Basic Required Hand Tools
Clip Removal Tool
Rust Inhibitor (Primer)
Notes to the Installer:
1) Read the entire installation instructions prior to beginning the installation
of this accessory.
2) Make sure the vehicle is completely clean before the accessory is installed.
3) Ensure the vehicle is properly protected in the area(s) that the accessory is to
be installed.
4) To prevent vehicle damage, never place tools on top of painted surfaces, seats,
dash pad, console or floor carpet/mats.
5) Always wear appropriate safety gear to include gloves and safety glasses when required.
Notes to the Customer:
1) This vehicle's Cargo Net is equipped with upper bungee hook clips to aid in the retention of items placed in the
Cargo Net.
2) It is recommended that when not using the Cargo Net to carry items, that the hook clips remain unfastened.
See step 2 on page 6 for details.
3) Contained are detailed instructions for the use of the hook clips. After installation of the Cargo Net, please place the
installation instructions in the vehicle glove compartment for later use if needed.
Cargo Nets are constructed of elastic and netting. Please use caution to avoid entanglement.
Avoid eye injury. DO NOT overstretch the Cargo Net, ALWAYS keep your face and body out of the
Cargo Net's recoil path.
5INS131600HI
Vehicle Model
Sonata
Model Year
2015 ~
C2017 ADU01
Part No.
C2017 ADUP1
Note: Difficulty stated above reflects the minimum level of expertise required to install
the accessory.
( A ) Customer
Electric Drill 1/4" Drill Bit
Masking Tape Deburring Tool
HYUNDAI Genuine Accessories
Accessory
Difficulty
( B ) Dealer Technician
Denotes quality processes to be
checked prior to moving to the next
step.
Denotes specific tools that are
necessary to complete the step.
Denotes instructional steps
necessary to complete the
process.
FMVSS 110
Compliance
Information
Part Number:
C2017 ADU01
C2017 ADUP1
Drill Stop
Vacuum Cleaner
Revision Date
06/17/2014
Cargo Net
( B )
( C ) Master Technician
Denotes safety equipment required to be
used such as a mask, safety glasses, gloves,
and hearing protection.
Safety Glasses
Mask
Gloves Hearing Protection
All dealers must determine if
the weight they have added in
the form of all options or
accessories, when added to
the weight of all Port/Dealer
Installed options or
accessories, exceeds the
lesser of 1.5% of GVWR or 100
0.364 lbs
lbs. If the additional weight
0.165 kg
does exceed the lesser of the
(Gross
indicated thresholds, a "Load
Weight)
Carrying Capacity Reduced"
label must be installed. A
black, fine-point, indelible
marker must be used to write
by hand onto the label, the
reduced carrying capacity in
kilograms or pounds, which is
the total weight of all added
options and accessories.
Load Label Part Number:
NP070 - 09003
Page 1 of 7
