Trion MV20 Specifications

The 'Economy - Priced' solution for the collection of dust, the freestandinging MV9 & MV20 are ideal
for collection at source of most dry particulate ie. powder, grinding, polishing and buffing dusts.
The bag filter is a cleanable polyester needlefelt bag which is cleaned by a hand operated shaker
system which deposits the collected particulate into a removable collection box.
Typical applications are dust from working with metal, stone, wood or synthetic materials. The
collector dust can be discharged and collected in a dust drawer (standard) or a dust hopper
(optional) with legs.
Motor starter relays with on/off switch are supplied with the units for special applications. Explosion
protected motors, blowers and filter bags in anti static finish are also available.

Specifications

Airflow Volume M 3 /hr
External Static Pressure in PA
Length (mm)
Width (mm)
Height (mm)
Inlet Dia. (mm)
Noise Level in dB(A)
Motor (Kw)
Electrical Supply
Current in Amps
Weight (kg)
TRION
MV9
&
MV20

FEATURES AND BENEFITS

MV9
900
1200
550
650
1180
125
72
.75
230 / 400 / 50Hz
3.1 / 1.8
130
®
MV20
2000
1800
750
850
1600
200
75
2.2
400 / 50Hz
8.1 / 4.7
220
