The TRION CV Series units are freestanding, self-cleaning cartridge filters with Pulse-Jet cleaning, which
was manufactured especially for removal of all kinds of dry smoke and dust (not explosive or flammable).
The filter cabinet is made from 1.5mm welded sheet metal. A silent centrifugal fan is integrated in the top
area of the unit. The unit is also supplied on a stand with a collection hopper and dust barrel which can be
easily removed and emptied.
The self-cleaning system utilises compressed air which is stored in tanks on the outside of the unit, the
compressed air is then led directly through the tank into the cartridges. Alternatively, the cartridges can be
cleaned
during operation (on-line) or through pressure difference, which saves on compressed air.
Additionally, there is an off-line cleaning system installed. The control box with a filter monitoring mechanism
for cleaning is included. The interval-pulse sequences are individually adjustable as are the x-P-value
settings.
Changing the cartridges is made easy by the large doors on the front of the unit. The larger dust
particles are led directly into the collection hopper through a buffle which is installed at the air inlet.
The unit price includes a compressed air maintenance system with a reverse-safety valve, water filter and
pressure valve. The compressed air can be alternatively be supplied through a flexible hose with a standard
coupler plug or through a stiff tube system.
Technical Details
Air Volume m
3
/h
Main Filter Area
Filter Area total
Noise Level
Input Voltage
Power
Efficiency
Fan
Cleaning System
Dust Collector Hoppers
Inlet Connection (mm)
Height inlet connection (mm)
Height (mm)
Width (mm)
Depth (mm)
Weight kg
Nominal resistance through unit
with celulose cartridge
Available resistance external to unit
TRION
Model: CV2
CV2
2040
26m
2
(2 x filters)
52m
2
75 dBA
400V / 3ph / 50Hz
2.2 Kw
99.93%
Backward
Pulse Jet
1
200
1460
2920
750
850 + 200 Tank
318
1000 PA
500 PA
®
Model CV4 (shown)
CV4
4080
26m
2
(4 x filters)
104m
2
75 dBA
400V / 3ph / 50Hz
3.0 Kw
99.93%
Backward
Pulse Jet
2
200mm x 2
1460
3170
1500
850 + 200 Tank
455
1000 PA
1200 PA
Advertisement
Table of Contents
Related Manuals for Trion CV2
Summary of Contents for Trion CV2
- Page 1 TRION Model: CV2 The TRION CV Series units are freestanding, self-cleaning cartridge filters with Pulse-Jet cleaning, which was manufactured especially for removal of all kinds of dry smoke and dust (not explosive or flammable). The filter cabinet is made from 1.5mm welded sheet metal. A silent centrifugal fan is integrated in the top area of the unit.
-
