Page 2: Important Safety Information
Under no circumstances should you attempt to repair ● the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Tricity Bendix Service Force Centre. Always insist on genuine Tricity Bendix spare parts. -
Page 3: Table Of Contents
Contents For the User Important Safety Information Your New Washing Machine Description of the Appliance Detergent dispenser drawer Child safety feature The Control Panel Programme information Operating sequence Load the laundry Measure out the detergent and the fabric softener Switch the machine on Select the required programme Select the spin speed or the “rinse hold”... -
Page 4: Your New Washing Machine
Your New Washing Machine Your new washing machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Even small loads are washed “economically” because the amount of water used is regulated automatically according to the load and type of fabric. Automatic cooling of the wash water to 60°C ●... -
Page 5: Description Of The Appliance
Description of the Appliance 1 Detergent dispenser drawer 2 Control panel 3 Door opening handle 4 Filter 5 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener Child safety feature This machine incorporates a special child safety feature to prevent small children from being trapped inside the machine. -
Page 6: The Control Panel
The Control Panel 1 Detergent dispenser drawer 2 Mains-on light This light comes on when the “on/off” button is pressed, and goes out when it is pressed again. 3 “On/Off” button Press this button to switch the machine on. Press it again to switch the machine off. -
Page 7: Programme Progress Display
6 “prewash “button The machine performs a prewash cycle at 30°C max. The prewash cycle ends with a short spin at 650 r.p.m. in programmes for cottons and synthetics, and with emptying of the water for delicates. This option is not available with the wool/(handwash) programme , soak 30 and mini 30. -
Page 8: Programme Information
The selector dial can be turned either clockwise or anticlockwise. Position E in cottons and synthetics sectors corresponds to the ENERGY SAVING programmes and position to “cold wash”. At the end of the programme the selector dial must be turned to position “off” (reset) and the “on/off” button must be pressed to switch the machine off. -
Page 9: Operating Sequence
“softener” Hand washed cotton garments can be softened with this programme. The machine performs 1 rinse, followed by a final spin at the max. speed, which can be reduced by depressing the “spin” button. “drain” For emptying out the water of the last rinse in programmes with the “rinse hold”... -
Page 10: Select The Spin Speed Or The "Rinse Hold" Option
The pilot lights corresponding to the different phases making up the selected programme light on. If your laundry needs a soak time, turn the programme selector dial to “soak 30” and then, before starting a washing cycle, drain the water as described in the “End of Soak 30 programme ”... -
Page 11: Washing Hints
Washing Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance. The average weights of the most common items are listed below as a guide: 1000g = 1 kg Sheet Pillow case Tablecloth Serviette Tea towel Linen hand towel... -
Page 12: Which Detergent
Which detergent?... To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines. To maintain the appearance of your clothes and household textiles and to make them last longer you should use different types of detergent for different washes, whether for whites, colours or delicates. -
Page 13: Wash Care Symbols
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 14: Washing Programmes
Washing Programmes ype of Section Temp. fabric Cottons 95° Whites Cottons E95° Whites Economy Whites and *Cottons E60° Fast colours Colours Economy Cottons E40° Non-fast Cottons colours 30°-40° (Cold) Synthetics Synthetics 60° Synthetics Economy Synthetics E60° Synthetics 30°-40° Synthetics (Cold) Delicates Delicates 30°- 40°... -
Page 15: Special Programmes
Special Programmes Programme Programme description Soak 30 Soak at 30°C for about 30 minutes. Stop with water in the tub. 3 rinses with liquid additive Rinses if required Long spin 1 rinse with softener Softener Short spin For emptying out after the Drain programme Soak 30°... -
Page 16: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. -
Page 17: The Dangers Of Freezing
Unscrew and remove the filter. Clean carefully under a fast running tap. Warning When the appliance is in use and depending on the programme selected there can be hot water in the filter. Never remove the filter during a wash cycle, always wait until the appliance has finished the cycle, and is empty. -
Page 18: Something Not Working
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 19: Service And Spare Parts
Customer Care Department For general enquiries concerning your Tricity Bendix appliance or for further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.tricity-bendix.co.uk. -
Page 20: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if, within 12 months of the date of the purchase, this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our... -
Page 21: Installation Instructions
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 22: Unpacking
Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all the packaging for re-use in case the machine is to be transported again. Using a spanner unscrew and remove the rear right bolt. Lay the machine gently on its back, making sure that the hoses are not squashed. -
Page 23: Water Drainage
If you cannot make the cold water connection direct from the rising mains, you may be able to operate the appliance from your cold water storage system. There should be a minimum vertical distance of 5.02m (16.5 ft) between the appliance’s inlet and the bottom of the water storage tank. -
Page 24: Levelling
Important Before connecting the machine to new pipework or ● to pipework that has not been used for some time, run off a reasonable amount of water to flush out any debris that may have collected in the pipes. For a correct functioning of the machine the drain ●... -
Page 25: Electrical Connection
Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance’s rating plate. -
Page 26: Building-In
Building-in This appliance has been designed to be built into the kitchen furniture. The recess should have the dimensions shown in picture When installing the appliance into the kitchen furniture ensure, if possible, the hoses are placed in either of the two recesses on the back of the appliance. - Page 27 If the door has to be opened from left to right, invert the position of the plates (7), the magnet (4) and the plate (5) (Fig. B and E). Mount the countermagnet (6) and the hinges (1) as previously described. Recommendations regarding the construction and fitting of a base when the installation requires an...
