Summary of Contents for DeltaTRAK FlashCheck 12237
- Page 1 User Guide Model 12237 Certified Min/Max Alarm Thermometer...
-
Page 3: Table Of Contents
Table of Contents Before you begin ..............Check Inside the Box ............Installing New Battery ............. The Liquid Crystal Display (LCD) ........Control Buttons ............... Basic Features ..............Display Modes ..............Changing the Display Modes .......... Resetting the Min-Max Readings ........Clearing the Alarm Indication .......... -
Page 4: Before You Begin
• Insert the battery into the battery holder The LCD will light up and you will hear a beep. Then the device displays the temperature reading from the sensor and the current Max and Mi readings. • Close the battery door and tighten the retaining screw www.deltatrak.com... -
Page 5: The Liquid Crystal Display (Lcd)
Note: The instrument has no power off button, so if it needs to be stored without power then the battery must be removed Basic Features Display Modes • Max-Min Reading The LCD displays the current temperature reading, the maximum reading and minimum readings. This is the default operation mode. www.deltatrak.com... -
Page 6: Changing The Display Modes
Configuring the Thermometer Clearing the Alarm Indication During Max-Min or High-Low display mode click the Clear button. The Alarm indica- tion is reset until the sensor reading is again above or below the High or Low alarm setpoints respectively. www.deltatrak.com... -
Page 7: Entering The Configuration Mode
“On”, the bell icon flashes every 3 seconds with a beeping sound. • Exiting the Configuration Menu After menu # 6, click the Mode button again to exit the Configuration mode or leave it to expire after 1 minute and return to the previous display mode. www.deltatrak.com... -
Page 8: Battery Replacement
When no battery life is left the indicator is empty and flashing. The battery must be replaced when this condition occurs. The configuration settings will be preserved when the battery is replaced with in 1 min after removing it from the instrument. www.deltatrak.com... - Page 9 3 seconds to enter screen to the next menu if High-Low values Configuration Menu option. were entered. Oth- Mode. MODE erwise, it moves to Configuration Menu Mode. Increase a set point value. Only used during configuration Mode. Decrease a set point value. www.deltatrak.com...
- Page 10 Settings 1 & 2 are not operational. Sound Alarm On: when alarm is triggered, a beeping (On or Off) sound will be activated. Temperature Use Up & Down arrows to select Celcius or Scale Farenheit scale. °C (°C or °F) www.deltatrak.com...
- Page 11 Notes: www.deltatrak.com...
- Page 12 Limited Warranty DeltaTrak instruments have a limited warranty period of 1 year against defects in materials and workmanship from the date of purchase. Accessory items and sensors have a limited warranty of 3 months. Repair services have a limited warranty period of 3 months against defects in materials and workmanship.
