- Page 1 INSTRUCTION BOOKLET GAS HOB MODEL TBG 640 Please read this instruction booklet before using the appliance...
-
Page 3: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 950950 Installation This hob must be installed by qualified personnel, according to the manufacturer’s instructions and to the relevant British Standards. -
Page 4: Table Of Contents
Contents For the User Description of the Hob Operation Maintenance and Cleaning Something Not Working? Service and Spare Parts Guarantee Conditions Page 9 Guide to Use the instructions The following symbols will be found in the text to guide you throughout the Instructions: Safety Instructions Step by step instructions for an operation... -
Page 5: Description Of The Hob
Description of the Hob 1. Hob Top 2. Rapid Burner 3. Semi-rapid Burners 4. Auxiliary Burner 5. Control knob for back right burner (semi-rapid) 6. Control knob for back left burner (semi-rapid) 7. Control knob for front left burner (rapid) 8. -
Page 6: Operation
Take care when frying food in hot oil or fat, as the overheated splashes could easily ignite. If the control knobs become difficult to turn, please contact your local Tricity Bendix Service Centre. maximum diameter 260 mm. 220 mm. -
Page 7: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. -
Page 8: Something Not Working
There is no spark when lighting the gas The gas ring burns unevenly If after all these checks, your hob still does not operate correctly, contact your local Tricity Bendix Service Force Centre. When you contact them, they will need the following information: 1. -
Page 9: Service And Spare Parts
Service Force Centre by telephoning: 08705 929929 Your call will be routed to the Service Centre covering your post code area. The addresses of Tricity Bendix Service Force Centres are detailed on the following pages. TRICITY BENDIX STANDARD GUARANTEE CONDITIONS... -
Page 10: Tricity Bendix Service Force
TRICITY BENDIX SERVICE FORCE To contact your local Tricity Bendix Service Force Centre telephone 08705 929 929 CHANNEL ISLANDS GUERNSEY Guernsey Electricity PO Box 4 Vale , Guernsey Channel Islands JERSEY Jersey Electricity Company PO Box 45 Queens Road St Helier... - Page 11 TRICITY BENDIX SERVICE FORCE To contact your local Tricity Bendix Service Force Centre telephone 08705 929 929 MIDLANDS BIRMINGHAM 66 Birch Road East, (M18) Wyrley Road Industrial Estate Witton Birmingham B67DB BOURNE Manning Road Ind (M44) Estate Pinfold Road Bourne...
-
Page 12: Instructions For The Installer
Instructions for the Installer OVERALL DIMENSIONS Width: 580 mm. Depth: 500 mm. Height: 88 mm. CUT OUT DIMENSIONS Width: 550 mm. Depth: 470 mm. Thickness: 30 mm. Ignition HT Spark Spark Generator Ispra Control's BF 50046 - 230-240V 0.6 YA T 120 Spark Gap Fixed Rear Left Burner (semi rapid) -
Page 13: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). Detailed recommendations are contained in the following British Standards Codes Of Practice: B.S. 6172/ B.S. -
Page 14: Installation
Installation IMPORTANT This hob must be installed by qualified personnel to the relevant British Standards. Any gas installation must be carried out by a registered CORGI installer. The manufacturer will not accept liability, should the above instructions or any of the other safety instructions incorporated in this book be ignored. -
Page 15: Building In
Building In Building over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface. -
Page 16: Electrical Connection
Electrical connections Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS HOB MUST BE EARTHED. The manufacturer declines any liability should these safety measures not be observed. -
Page 17: Wiring Diagram
Wiring diagram 220/240 A. IGNITOR SWITCH B. IGNITOR UNIT... -
Page 18: Fault Finding
Fault Finding Preliminary Electrical Systems Check Blue Brown Green Yellow START Isolate appliance and carry out: A: Earth Continuity check. Blue Green Brown Yellow Has inlet fuse blown? Inlet wiring faulty. Rectify any fault. PLUG (with cover removed) Earth Wire Green/Yellow Neutral Wire Blue... -
Page 19: Ignition System / Gas Ignition
Ignition System / Gas Ignition Ignitor does not spark Check plug top fuse and replace if necessary Check polarity and earth continuity of supply point Check earth continuity of appliance Check continuity from 'N' on the mains connector block and "O" on the ignitor unit Check continuity from 'L' on the mains connector block and the... -
Page 20: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. - Turn the gas tap to the MAX position and ignite. - Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 21: Conversion From Natural Gas To Lpg
Conversion from Natural Gas to LPG It is important to note that this model is designed for use with natural gas but can be converted for use with butane or propane gas providing the correct injectors are fitted. The gas rate is adjusted to suit. Method •...
