Summary of Contents for Tricity Bendix E 750
-
Page 1: Operating And Installation Instructions
OPERATING AND INSTALLATION INSTRUCTIONS MODEL NO. E 750... -
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using the cooker. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department. The address is on the back page of this book. -
Page 3: Table Of Contents
CONTENTS FOR THE USER Important Safety Information Description of the cooker Getting to Know Your Oven The Cooling Fan for the Controls Control Panel Indicator Neons Before Using The Cooker Rating Plate When First Switching On The Fan Selector Button Condensation and Steam Cookware The Trivet... - Page 4 FOR THE INSTALLER Technical Details Things You Need to Know Warnings Choice of Electrical Connection Things to Note Preparing Cabinet for Fitting Oven How to Finish Unpacking Making the Electrical Connections To Remove Cover of Mains Terminal Connecting to the Mains Terminal Checking Electrical Connections Connecting to a Hob or Cooker Point...
-
Page 5: Description Of The Cooker
DESCRIPTION OF THE COOKER Built in electric double oven WARNING: THIS COOKER MUST BE EARTHED Your built in cooker comprises of an oven with conventional and fan assisted option and dual grill in the top compartment. The top oven is convenient and economical for mid-week use because of its size. The main fan oven is the larger of the two ovens. -
Page 6: Getting To Know Your Oven
GETTING TO KNOW YOUR OVEN The Control Panel Fan Selector button for Convenience Oven Dual Grill Control Convenience Oven Temperature Control Fan Oven Temperature Control Electronic Timer Fan Selector Indicator Neon Dual Grill Indicator Neon Convenience Oven Indicator Neon Fan Oven Indicator Neon... -
Page 7: The Cooling Fan For The Controls
THE COOLING FAN FOR THE CONTROLS Your cooker has a cooling fan fitted behind the controls to prevent them from overheating. The cooling fan will come on immediately with the grill or when thermal grill is selected and after a short time when either of the ovens are in use. -
Page 8: Before Using The Cooker
BEFORE USING THE COOKER WHEN FIRST SWITCHING ON The timer must be set to manual operation before the main fan oven can be operated. This must be done whenever the cooker is switched off at the wall or when there has been a power failure. -
Page 9: Condensation And Steam
CONDENSATION AND STEAM When food is heated it produces steam in the same way as a boiling kettle does. The ovens are vented to allow some of this steam to escape. However, always stand back from the cooker when opening the oven doors to allow any build up of steam or heat to release. -
Page 10: Grill And Oven Furniture
GRILL AND OVEN FURNITURE The following items of oven furniture have been supplied with the cooker. 1 grill pan 1 grill pan handle 1 grill pan grid 1 trivet 1 meat tin 2 shelves for main oven cooking 2 shelves for grilling and Convenience oven cooking Scuffing of the Stayclean sides and back panel by the oven furniture pack... -
Page 11: The Electronic Timer
THE ELECTRONIC TIMER The electronic timer can indicate the time of day, operate minute automatically time the main fan oven. A Auto Symbol ( automatic cooking ) Bell Symbol ( minute minder ) Cookpot Symbol ( manual cooking ) Please note that this is a 24 hour clock, for example 2pm is shown as 14.00. - Page 12 AUTOMATIC TIMER CONTROL The automatic timer can be used with the main fan oven only. TO SWITCH THE MAIN OVEN ON AND OFF AUTOMATICALLY 1. Ensure the clock is showing the correct time of day. 2. Place food in the main oven. 3.
- Page 13 5. Turn oven control temperature. The clock will work out what time the oven will switch itself on and will switch the oven off at the end. An audible signal will sound when cooking is complete. To cancel the alarm, see below.
- Page 14 At the end of the cooktime the oven will switch off, the alarm will sound and the auto symbol will flash. 5. To cancel and return to manual operation press buttons together. 6. Turn off the oven temperature control.
-
Page 15: The Dual Grill
THE DUAL GRILL WARNING - Accessible parts become hot when the grill is in use. Keep children away. USES OF THE GRILL The grill is situated in the Convenience oven compartment. The grill is a dual circuit grill which means that the full area of the grill or the centre section only can be used. -
Page 16: The Grill Pan And Handle
THE GRILL PAN AND HANDLE The grill pan has a removable handle. To insert the handle, press the button on the handle with the thumb and pivot the handle slightly upwards inserting the lip into widest part of the bracket. Move the handle towards the left, lower into position and release the button. - Page 17 The grill pan grid is reversible. This is useful if you want to cook foods of varying thickness. As a general rule, bread for toasting should be placed on the grid in the ' high ' position in the grill pan. Foods such as chicken pieces or chops may be grilled using the grilling grid in the low position.
-
Page 18: Grilling Chart
GRILLING CHART The chart below gives recommended cooking times and shelf positions. Remember that these are a guide and should be adjusted to suit personal taste. Note Shelf positions are counted from the bottom upwards. FOOD Bacon Rashers Beefburgers Chicken Joints Chops - Lamb - Pork Fish - Whole Trout / Herring... -
Page 19: The Fan Assisted Convenience Oven
THE FAN ASSISTED CONVENIENCE OVEN USES OF THE FAN ASSISTED OVEN The Convenience oven is the smaller of the two ovens. It is convenient for mid-week meals where smaller quantities or convenience foods are being cooked. It is important to refer to the Convenience oven cooking chart as a guide to shelf positions and temperatures as these may differ from previous cookers you may have... -
Page 20: Hints And Tips
HINTS AND TIPS Use the Convenience oven when you want to warm plates. Use a setting of 80°C - 100°C on the oven temperature control. You can use both shelves when using the fan assisted oven. There should always be at least 2.5cm (1") between the top of the food and the grill element. -
Page 21: The Conventional Convenience Oven
THE CONVENTIONAL CONVENIENCE OVEN USES OF THE CONVENTIONAL OVEN This form of cooking gives you the opportunity to cook without the fan in operation. It is particularly suitable for some cook chilled convenience foods and dishes which require extra base browning such as pizzas, quiches and flans. -
Page 22: Hints And Tips
HINTS AND TIPS The middle shelf allows for the best heat distribution. To increase base browning simply lower the shelf position. To increase top browning, raise the shelf position. The material and finish of the baking trays and dishes used will affect base browning. Enamelware, dark heavy or non-stick utensils increase base... -
Page 23: Convenience Oven Cooking Chart
CONVENIENCE OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by a further 10°C to suit individual preferences and requirements. Note: Shelf positions are counted from the bottom of the oven. FOOD Biscuits Bread... -
Page 24: Thermal Grilling In The Convenience Oven
THERMAL GRILLING IN THE CONVENIENCE OVEN USES OF THERMAL GRILLING Thermal grilling in the Convenience oven offers an alternative method of cooking food items normally associated with conventional grilling. The grill element and the oven fan operate together, circulating hot air around the food. The need to check and turn food is reduced. -
Page 25: Things To Note
THINGS TO NOTE Setting 4 is suitable for most foods. The Grill indicator neon will glow throughout cooking. Selector indicator neon will glow throughout cooking. The oven fan will operate continually during thermal grilling. The cooling fan for the controls will come on when the grill control is turned. -
Page 26: Thermal Grilling Chart
Turn food over during cooking as necessary. Ensure that ready prepared or cooked chilled dishes e.g. shepherds lasagne, etc., are piping hot throughout before serving. Grilling at setting 4 and shelf position 3 is suitable for most foods. Be prepared to make suitable adjustments during cooking to suit individual requirements. -
Page 27: To Cool And Defrost In The Convenience Oven
TO COOL AND DEFROST IN THE CONVENIENCE OVEN USES OF COOLING AND DEFROST This function enables you to cool down hot food and defrost most foods without heat faster than some conventional methods as the oven fan circulates air around the food. It is particularly suitable for defrosting delicate frozen foods which are to be served cold e.g. - Page 28 Joints of meat up to 2kg/4½lb in weight can be thawed using the defrost function. All joints of meat and poultry must be thawed thoroughly before cooking. DO NOT leave food at room temperature once defrosted. Cook food immediately or store cooked food in the fridge.
-
Page 29: The Main Fan Oven
THE MAIN FAN OVEN USES OF THE FAN OVEN The main fan oven is particularly suitable for cooking larger quantities advantages of fan oven cooking are: PREHEATING The fan oven quickly reaches its temperature so it not usually necessary to preheat the oven. Without preheating however you may need to add an extra 5 - 10 minutes on the recommended cooking times. -
Page 30: To Fit The Fan Oven Shelves
TO FIT THE FAN OVEN SHELVES The shelves should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. If not fitted correctly the anti-tilt and safety stop mechanism will be affected. HINTS AND TIPS Arrange the shelves in the required positions before switching the oven on. -
Page 31: Fan Oven Cooking Chart
FAN OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by a further 10°C to suit individual preferences and requirements. Note: Shelf positions are counted from the bottom of the oven. FOOD Biscuits Bread... -
Page 32: Roasting Chart
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES Rare: 50 - 60°C; Medium: 60 - 70°C; Well Done: 70 - 80°C MEAT Beef Beef, boned Mutton and Lamb Pork and Veal Chicken Turkey and Goose Duck Pheasant Rabbit Potatoes with meat Potatoes without meat The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat. -
Page 33: Defrosting In The Main Fan Oven
DEFROSTING IN THE MAIN FAN OVEN USES OF DEFROST FEATURE This main oven function enables you to defrost most foods without heat faster than some conventional methods circulates air around the food. It is particularly suitable for delicate frozen foods which are to be served cold e.g. - Page 34 Joints of meat up to 2kg/4½lb in weight can be thawed using the defrost function. All joints of meat and poultry must be thawed thoroughly before cooking. Always cook thoroughly immediately after thawing. DO NOT leave food at room temperature once defrosted.
-
Page 35: Care And Cleaning
CARE AND CLEANING Before cleaning the cooker always allow the cooling fan for the controls to cool the cooker down before switching off the electricity supply. CLEANING MATERIALS Before using any cleaning materials on your cooker, check that they are suitable and that their use is recommended by the manufacturer. -
Page 36: Cleaning The Outer And Inner Door Glass Panels
CLEANING THE OUTER AND INNER DOOR GLASS PANELS To prevent damaging or weakening the door glass panel avoid the use of the following: Household detergents and bleaches Impregnated pads unsuitable for non-stick saucepans Brillo/Ajax pads or steel wool pads Chemical oven pads or aerosols Rust removers Bath/Sink stain removers outer... -
Page 37: Cleaning Inside The Ovens
TO REPLACE THE OUTER DOOR GLASS 1. Holding the door glass panel with both hands, gently place the locators into the holes of the brackets at the bottom of the oven door. 2. Holding the door glass with your left hand, use your right hand to open the oven door. -
Page 38: To Remove The Wirework Runners
TO REMOVE THE WIREWORK RUNNERS The wirework runners in both ovens can be removed for cleaning. 1. Remove all shelves and furniture from the oven. 2. Hold the wirework at the bottom and gently pull towards the centre of the oven. 3. -
Page 39: The Oven Cleaning Cycle
THE OVEN CLEANING CYCLE - BOTH OVENS 1. Remove oven shelves, wirework runners and bakeware from oven. 2. Turn the required oven temperature control to 220°C and allow the oven to run for an hour or so. 3. To clean the Convenience oven push in the Fan Selector button. -
Page 40: Replacing The Oven Light Bulb
Use minimal, if any, extra oil or fat when roasting meat, potatoes only require brushing with fat before cooking. Extra fat in the oven during roasting will increase splashing and soilage. It is not necessary to add water to the meat tin when roasting. -
Page 41: If Something Doesn't Work
IF SOMETHING DOESN'T WORK Please carry out the following checks on your cooker before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the cooker is under guarantee. - Page 42 The oven light fails to illuminate The oven fan is noisy The oven temperature is too high or low The oven light bulb may need replacing see page 40. If the Main Fan Oven is set for automatic cooking the light will illuminate when the cook time begins.
-
Page 43: Guarantee Conditions
GUARANTEE CONDITIONS Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or... -
Page 44: Service And Spare Parts
Please note that all enquiries concerning service should be addressed to your local Service Centre. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Tricity Bendix cooker or for further information on Tricity Bendix products, you are invited to contact our Customer Care Department by letter or telephone as follows:... -
Page 45: Customer Service Centres
TRICITY BENDIX SERVICE FORCE 0990 929929 To contact your local Tricity Bendix Service Centre telephone CHANNEL ISLANDS NORTH EAST SCOTLAND NORTHERN IRELAND WALES NORTH WEST... - Page 46 TRICITY BENDIX SERVICE FORCE To contact your local Tricity Bendix Service Centre telephone MIDLANDS Unit 7 Oaks Industrial Estate Coventry Road Narborough Leicestershire LE9 5GF LONDON & EAST ANGLIA WEST DRAYTON 2 / 4 Royal Lane (M76) Yiewsley West Drayton...
-
Page 47: Technical Details
TECHNICAL DETAILS Voltage: 230\240 Volts AC 50Hz Loading Info: Top Oven* 1.7kW Dual Grill: 2.8kW Base Element: 1.0kW Main Oven Fan Element: 2.5kW Fan Motor: 0.03kW Oven Light: 0.05kW Wattage: 5.0\5.5kW Height: 720 mm Width: 593 mm Depth: 585 mm (excluding handles and knobs) * Cannot be used at the same time as the grill element. -
Page 48: Things You Need To Know
INSTALLATION INSTRUCTIONS THINGS YOU NEED TO KNOW WARNINGS: WARNINGS: This cooker must be installed by a qualified electrician/competent person. Safety may be impaired if installation is not carried out in accordance with these instructions. This cooker must be earthed. Do not remove the screws from the earth tab extending from the oven mains terminal block (Fig. -
Page 49: Things To Note
INSTALLATION INSTRUCTIONS NOTE: It is good practice to: Fit an Earth Leakage Circuit Breaker to your house wiring. Wire your appliance to the latest IEE regulations. THINGS TO NOTE This cooker is designed to be fitted between cabinets with the recommended dimensions as shown in Fig. -
Page 50: Preparing Cabinet For Fitting Oven
INSTALLATION INSTRUCTIONS PREPARING CABINET FOR FITTING OVEN Make sure the space between the cabinets is the correct size for the appliance to be fitted (Ref. Fig. 5 & 6). The plinth board spanning the space into which the appliance is to be installed should be removed. -
Page 51: How To Finish Unpacking
INSTALLATION INSTRUCTIONS Check that the mounting brackets are level. They can be adjusted if necessary by using the extra holes at the ends of the brackets. Once the brackets are level, drill a pilot hole through the central hole in the bracket and fit the remaining screw HOW TO FINISH UNPACKING Place packed cooker next to the space in... -
Page 52: Making The Electrical Connections
INSTALLATION INSTRUCTIONS TO REMOVE COVER OF MAINS TERMINAL From the rear of the cooker, remove mains input terminal cover to gain access to terminal block. First remove retaining screw with pozidrive screwdriver. See Fig. 9. Prise cover loose using screwdriver in position (1) then lever off with screwdriver in position (2) at either side. -
Page 53: Connecting To The Mains Terminal
INSTALLATION INSTRUCTIONS CONNECTING TO THE MAINS TERMINAL Warning: This cooker must be earthed. We recommend you use a new length of twin core and earthed cable to ensure your safety. Make connection as shown in Fig. 12 by proceeding as follows:- Preform wires to the appropriate shape to suit fitting into the mains terminal block. -
Page 54: Checking Electrical Connections
INSTALLATION INSTRUCTIONS CHECKING ELECTRICAL CONNECTIONS Confirm the cooker is correctly connected by switching on and observing the various oven functions indicators. The electronic timer will flash on and off. CONNECTING TO A HOB OR COOKER POINT Either follow in general terms the instructions for connecting to the terminal block or refer to the hob suppliers installation instructions. -
Page 55: Fitting Into The Space Between Cabinets
INSTALLATION INSTRUCTIONS FITTING INTO THE SPACE BETWEEN CABINETS IMPORTANT: Ensure that the oven is switched off at the wall before any further work is carried out. Ensure the cooker is in front of the cabinet. See Fig. 13. Take out all oven furniture before installation to reduce the weight you need to lift. - Page 56 This handbook is accurate at the date of printing, but will be superseded and should be disregarded if specifications or appearance are changed. TRICITY BENDIX,PO BOX 47,NEWBURY,BERKSHIRE, RG14 5XL TELEPHONE (01635) 525542 MODEL NO. PART NO.
