- Page 1 Manual for use and maintenance Spare part list EDC GHp Air circulation fan Models: EDC18 GHp - EDC24 GHp...
- Page 2 Warranty. Declaration of conformity Munters Italy S.p.A. with registered offices in Strada Piani 2 - 18027 Chiusavecchia (IM) - Italy (Company registration nr. 00081050080) Declares on its own responsibility that the apparatus EDC18GHp and EDC24GHp are conform to the following provisions: ...
-
Page 3: Table Of Contents
Spare parts - EDC18 GHp ..................16 Exploded view - EDC24 GHp ................. 17 Spare parts - EDC24 GHp ..................18 WARNING All the components and spare parts MUST be storaged in dry and clean environment. © Munters AB, 2020... -
Page 4: Introduction
EDC fans. 1.3 Notes Date of release: 2020. Munters cannot guarantee to inform users about the changes or to distribute new manuals to them. All rights reserved. No part of this manual may be reproduced in any manner whatsoever without the expressed written permission of Munters. -
Page 5: Safety Aspects
2. SAFETY ASPECTS The safety of fans is assured by Munters in compliance with the safety requirements indicated by the CE label. Safe functioning is assured only when the installation procedures and the instructions for use have been carefully followed. The following points must be stressed: •... -
Page 6: Before Using
Working ambient temperature limits are -15°C to +40°C. Maximum altitude is 1000 m above sea level. If a fan is required to operate at a higher altitude, the loss in mass flow (heat removing capacity) due to lower air density should be taken into consideration. © Munters AB, 2020... -
Page 7: Installation
IEC EN 60439-1, and arrange the wiring of the fan in accordance with the instructions in standards IEC EN 60204-1 and IEC 60364. The electrical panel of the fan must generally be equipped with the following devices (bearing EC marking as per directive 2006/95/EC): © Munters AB, 2020... - Page 8 5 WARNING Do not supply power to the fan during installation stage. Installer must issue a declaration of correct installation in accordance with applicable legislation in the country of use. © Munters AB, 2020...
- Page 9 • they must make an effective earth connection; • they must have isolating devices and automatic protection against overload and short circuits. © Munters AB, 2020...
-
Page 10: Use
Switching on and switching off Switching on and switching off operations pass through not supplied equipments. Operating conditions Looking at the airflow rectifier, the propeller should turn counterclockwise (fig.8). fig. 8 © Munters AB, 2020... -
Page 11: Commissioning
Wait until the electrical power has been switched off and the fan has come to a complete stand still. Lock the electrical switch in the off position with a pad lock while working on the fan. © Munters AB, 2020... -
Page 12: Technical Data
7. TECHNICAL DATA 7.1 Dimensions Dimensions fig.9 EDC24 GHp EDC18 GHp © Munters AB, 2020... -
Page 13: Motor Specifications
IP55 Electric motor winding insulation grade Max noise level at 1.95 m 75.8 75.5 76.5 * The value refers to 3 phases 50Hz single speed motors. Note: airflow data are measured at standard conditions (20°C, 1,013hPa) © Munters AB, 2020... -
Page 14: Maintenance
• check the absence of electrical continuity between the terminals upstream and downstream the thermo-magnetic switch; in case of electrical continuity replace the switch; • close the electrical control panel; • switch on the fan. © Munters AB, 2020... -
Page 15: Spare Part List
SPARE PART LIST Exploded view - EDC18 GHp © Munters AB, 2020... -
Page 16: Spare Parts - Edc18 Ghp
D5 SPRING WASHER D5x20 PLAIN WASHER POP UP RIVET D3.9x7 ALU HOUSING M6 HEX NUT RUBBER FOR CABLE M6x25 HEX SCREW W/FLANGE MOTOR D6 SPRING WASHER MOTOR PLATE D6 SPRING WASHER MOTOR PLATE SUPPORT D6x18 PLAIN WASHER © Munters AB, 2020... -
Page 17: Exploded View - Edc24 Ghp
Exploded view - EDC24 GHp © Munters AB, 2020... -
Page 18: Spare Parts - Edc24 Ghp
PROPELLER M8 HEX NUT MOTOR PLATE SUPPORT RUBBER FOR CABLE HOUSING POP UP RIVET D3.9x7 ALU M6x25 HEX SCREW W/FLANGE D8 SPRING WASHER MOTOR PLATE MOTOR ALUMINIUM HUB WASHER D8X32 D6 SPRING WASHER M6X20 HEX SCREW © Munters AB, 2020... - Page 19 7513 750, info@muntersform.com, Phone +1 517 676 7070, aghort.info@munters.com, Export & Other countries Phone +39 0183 5211, info@munters.it Munters reserves the right to make alterations to specifications, quantities, etc., for production or other reasons, subsequent to publication © Munters AB, 2020...
