- Page 1 OPERATING & INSTALLATION INSTRUCTIONS SLIP IN ELECTRIC COOKER SIE 252 PLEASE READ THIS INSTRUCTION BOOKLET BEFORE USING THE APPLIANCE...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. SIE 252 Voltage: Wattage: Height: Width: Depth: Weight: This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC 230-240 Volts AC 50Hz 7.4-8.1kW 900mm 500mm 600mm 45 kg... -
Page 3: Table Of Contents
CONTENTS Technical Details ... 2 Contents ... 3 Preface ... 5 Safety ... 6 Before Installation ... 6 During Operation ... 6 After Use ... 7 General ... 7 Introduction ... 8 Rating Plate ... 8 Installation ... 8 General Notes on Using Your Appliance ... 9 About Condensation and Steam ... - Page 4 CONTENTS Defrost Feature ... 19 Uses of Defrost Feature ... 19 Selecting Defrost ... 19 Things to Note ... 19 Hints and Tips ... 19 Care and Cleaning ... 20 Cleaning Materials ... 20 Cleaning the Sealed Hotplates and Hotplate Trims ... 20 Things to Note ...
-
Page 5: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix appliance, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. -
Page 6: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT YOU UNDERSTAND THEM ALL BEFORE INSTALLING OR USING THE APPLIANCE. PLEASE READ CAREFULLY BEFORE INSTALLATION This appliance is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the appliance has been removed before the appliance is used. -
Page 7: After Use
Take care recommendations given for tending the food when grilling. Do not leave the grill pan handle in position when grilling as it will become hot. Ensure that you support the grill pan when it is in the withdrawn or partially withdrawn position Ensure that... -
Page 8: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE This is situated on the lower front frame of the appliance and can be seen upon opening the door. Alternatively the rating plate may also be found on the back or top of some models (where applicable). The appliance must be protected by a suitably rated fuse or circuit breaker. -
Page 9: Fitting The Stability Bracket
Overhanging surfaces or a cooker hood should be a minimum of 685mm above the hob. It is important to ensure that the appliance is level after installation. Levelling feet are fitted to the appliance to accommodate uneven floors. FITTING THE STABILITY BRACKET It is recommended that a stability bracket supplied with the appliance be fitted during installation. -
Page 10: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL FEATURES - Hotplate Controls - Fan Oven/Grill Control - Oven/Grill Indicator Neon... -
Page 11: The Sealed Hotplates
THE SEALED HOTPLATES BEFORE USING THE HOTPLATES FOR THE FIRST TIME Turn the control knob to a medium/high setting and allow the hotplate to heat, uncovered by a saucepan for 3-5 minutes. This hardens the protective coating on the hotplates and makes it more resistant to normal use. A harmless smoke will be given off from the hotplates. -
Page 12: Deep Fat Frying
DEEP FAT FRYING SPECIAL FRYING NOTE: For safety purposes when deep fat frying, fill the pan one third full of oil, DO NOT cover the pan with a lid and DO NOT leave the pan unattended. unfortunate event of a fire, switch the appliance OFF at the electricity supply and cover the pan with a lid or damp cloth to assist in smothering the flames. -
Page 13: The Grill
THE GRILL USES OF THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL · To operate the grill, turn the oven/grill control clockwise until the grill setting oven/grill on the control panel. -
Page 14: Hints And Tips
To correctly locate the grill pan on the shelf, ensure that the cut out on the underside of the handle bracket locates over the front bar of the shelf. To check the progress of the food being grilled, the grill pan should be withdrawn on the shelf to tend the food during cooking. -
Page 15: The Fan Oven
THE FAN OVEN USES OF THE FAN OVEN The oven is heated by the element around the fan situated behind the back panel. The fan draws air from the oven, the element heats the air which is circulated into the oven via the vents in the back panel. The advantages of fanned oven cooking are: PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. -
Page 16: Hints And Tips
HINTS AND TIPS · Arrange the shelves in the required positions before switching the oven ON. Shelf positions are numbered from the bottom upwards. · When cooking more than one dish in the fan oven, place dishes centrally on different shelves rather than cluster several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results. -
Page 17: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. temperatures by 10°C to suit individual preferences and requirements. Shelf positions are counted from the bottom of the oven. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira... -
Page 18: Cooking Time
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C, Medium : 60-70°C, Well done : 70-80°C MEAT Beef Beef, boned Mutton and Lamb Pork and veal Chicken Turkey and Goose Duck Pheasant Rabbit Potatoes with meat Potatoes without meat The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat. -
Page 19: Defrost Feature
DEFROST FEATURE USES OF DEFROST This fan oven function defrosts most foods faster than more conventional methods. suitable for delicate frozen foods which are to be served cold e.g. cream filled gateaux, cakes covered with icings or frostings, cheesecakes, biscuits, scones etc. -
Page 20: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN WALL SWITCH AND ALLOW THE APPLIANCE TO COOL BEFORE CLEANING. CLEANING MATERIALS Before using any cleaning materials on your appliance, check that they are suitable and that their use is recommended by the manufacturer. -
Page 21: Cleaning The Grill And Oven Furniture
CLEANING GRILL FURNITURE All removable parts except the grill pan handle can be washed in the dishwasher. The grill pan and oven shelves may be cleaned using a soap impregnated steel wool pad. The grill pan grid should be cleaned using hot soapy water. Soaking first in hot soapy water will make cleaning easier. -
Page 22: Cleaning Between The Outer And Inner Door Glass
CLEANING BETWEEN THE OUTER AND INNER DOOR GLASS The outer door glass is removable for cleaning. TO REMOVE THE OUTER GLASS 1. Open the oven door slightly to gain access to the two cross head screws on the top of the oven door. -
Page 23: Something Not Working
SOMETHING NOT WORKING? Before calling an Engineer please carry out the following checks, you may be able to solve the problem without the expense of an engineer. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 24: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquires concerning your Tricity Bendix appliance, or further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below;... -
Page 25: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... -
Page 26: Notes
NOTES... - Page 27 NOTES...
- Page 28 Tricity Bendix, 55-77 High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number 08705 950950 IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed.
