- Page 1 OPERATING & INSTALLATION INSTRUCTIONS SLIP IN ELECTRIC COOKER SI505 PLEASE READ THIS INSTRUCTION BOOKLET BEFORE USING THE APPLIANCE...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. SI 505 Voltage: Wattage: Height: Width: Depth: Weight: This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. 230-240 Volts AC 50Hz 10.5-11.4kW 900mm 600mm 598mm 65kg... -
Page 3: Table Of Contents
CONTENTS Technical Details ... 2 Contents ... 3 Preface ... 5 Safety ... 6 Before Installation ... 6 During Operation ... 6 After Use ... 7 General ... 7 Introduction ... 8 Rating Plate ... 8 Installation ... 8 General Notes on Using Your Appliance ... 9 About Condensation and Steam ... - Page 4 CONTENTS Defrost Feature ... 24 Uses of Defrost Feature ... 24 Selecting Defrost ... 24 Things to Note ... 24 Hints and Tips ... 24 Care and Cleaning ... 25 Cleaning Materials ... 25 Cleaning the Ceramic Hob ... 25 Hints and Tips ...
-
Page 5: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix appliance, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures, which may differ, from your previous appliance. -
Page 6: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE APPLIANCE. PLEASE READ CAREFULLY BEFORE INSTALLATION This appliance is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the appliance has been removed before the appliance is used. -
Page 7: After Use
Take care recommendations given for tending the food when grilling. Ensure that you support the grill pan when it is in the withdrawn or partially withdrawn position. Ensure that unobstructed to ensure ventilation of the oven cavity. Ensure the anti-tilt shelves are put in place correctly. -
Page 8: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE This is situated on the front frame of the appliance seen upon Alternatively the rating plate may also be found on the back or top of some models (where applicable). The appliance must be protected by a suitably rated fuse or circuit breaker. -
Page 9: General Notes On Using Your Appliance
Note: Vapours from the oven vents may in time cause discolouration of wallcoverings behind the appliance. For ease of cleaning it may be preferable to tile behind the appliance. Overhanging surfaces or a cooker hood should be a minimum of 685mm above the hob. It is important to ensure that the appliance is level after installation. -
Page 10: Grill And Oven Furniture
GRILL AND OVEN FURNITURE The following items of grill/oven furniture have been supplied with appliance. require replacements of any of the items listed below please contact your local Service Force Centre, quoting the relevant part number. 1 grill pan (311409401) 1 grill pan handle (311468100) Note:... -
Page 11: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL - SI505 FEATURES - Timer - Fan Oven Temperature Control - Top Oven Temperature Control - Dual Grill Control - Hotplate Controls - Fan Oven Indicator Neon - Top Oven Indicator Neon... -
Page 12: The Timer
THE TIMER Please note that this is a 24 hour clock, for example Cookpot symbol Bell symbol 2.00pm is shown as 1400. In the following pages we explain how to set the controls. Read through them a few times until you are familiar with the procedure. -
Page 13: Setting The Controls For Automatic Use
AUTOMATIC CONTROL The automatic control can be used to control either oven, but you can only use the control for both ovens at the same time if the cooking time is the same. When you use the automatic controls for the first time it’s probably best to choose a time when you are at home. -
Page 14: The Ceramic Hob
THE CERAMIC HOB CAUTION: DO NOT USE THE APPLIANCE IF THE CERAMIC GLASS IS DAMAGED. IF A FAULT OR CRACK BECOMES VISIBLE DURING COOKING, DISCONNECT THE APPLIANCE IMMEDIATELY FROM THE ELECTRICITY SUPPLY AND CONTACT YOUR LOCAL SERVICE FORCE CENTRE. USING THE HOB ·... -
Page 15: Hot Hob Indicator
· To prolong the life of the hotplates:- · Never use utensils with a skirt, e.g. a bucket. · Never use an asbestos mat. · Never leave the hotplates ON when not covered with a saucepan. · Ensure that the hob and saucepans are clean and dry before the start of cooking to reduce cleaning. -
Page 16: The Dual Grill
THE DUAL GRILL USES OF THE DUAL GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. The grill is a dual circuit grill which means that the full area of the grill can be used for economy purposes, the centre section only can be used when cooking smaller quantities of food. -
Page 17: Hints And Tips
To check the progress of the food being grilled, the grill pan should be withdrawn on the shelf to attend to food during cooking. HINTS AND TIPS · In order to become acquainted performance of the Dual grill, it is advisable to check food regularly when grilling. -
Page 18: The Top Oven
THE TOP OVEN USES OF THE TOP OVEN The top oven is the smaller of the two ovens. It is heated by elements in the top and bottom of the oven. It is designed for cooking smaller quantities of food. It gives especially good results if used to cook fruit cakes, sweet or savoury flans or quiche. -
Page 19: Hints And Tips
HINTS AND TIPS · Most cooking should be carried out using an oven shelf positioned in one of the shelf runners. · Larger roasts and casseroles should normally be cooked in the main oven. However, they may be cooked on a flat shelf placed on the base of the top oven provided there is sufficient room for air circulation around the food. -
Page 20: The Main Fan Oven
THE MAIN FAN OVEN USES OF THE FAN OVEN The oven is heated by an element around the fan situated behind the back panel. The fan draws air from the oven and the element heats the air which circulates in the oven via the vents in the back panel. The advantages of fan oven cooking are: PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. -
Page 21: Hints And Tips
HINTS AND TIPS · Arrange the shelves in the required positions before switching the oven ON. Shelf positions are numbered from the bottom upwards. · When cooking more than one dish in the fan oven, place dishes centrally on different shelves rather than cluster several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results. -
Page 22: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperature by 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira Rich Fruit... -
Page 23: Roasting Chart
ROASTING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C; Medium : 60-70°C; Well done : 70-80°C MEAT Beef Beef, boned... -
Page 24: Defrost Feature
DEFROST FEATURE USES OF DEFROST FEATURE This main oven function defrosts most foods faster than more conventional methods. suitable for delicate frozen foods which are to be served cold e.g. cream filled gateaux, cakes covered with icings or frostings, cheesecakes, biscuits, scones, etc. -
Page 25: Care And Cleaning
CARE AND CLEANING BEFORE CLEANING THE APPLIANCE, ALWAYS ALLOW THE COOLING FAN TO COOL DOWN THE APPLIANCE BEFORE SWITCHING OFF AT THE ELECTRICITY SUPPLY. CLEANING MATERIALS Before using any cleaning materials on your appliance, check that they are suitable and that their use is recommended by the manufacturer. -
Page 26: Hints And Tips
HINTS AND TIPS TO REDUCE HOB SOILAGE: · Make sure the bottom of the saucepan and the cooking area are clean and dry before cooking begins. · Ensure saucepans accommodate food to avoid boil overs. · If possible, wipe up spills and splatters as they occur, but take care to avoid steam burns. -
Page 27: Care Of Stayclean Surfaces
The vitreous enamel in the grill compartment base and the fan oven base can be cleaned using normal oven cleaners or aerosol oven cleaners with care. Ensure that the manufacturers instructions are followed and that all parts are well rinsed afterwards. Aerosol cleaners must not be used on the Stayclean surfaces and must not come into contact with the elements or the door seal as this... -
Page 28: To Clean The Inner Glass Door Panels
TO REMOVE THE OUTER GLASS Open the oven door slightly to gain access to the two cross head screws on the top of the oven door. Loosen the two screws using a Pozidrive screwdriver. Hold the door glass securely in place with one hand before removing the screws completely with the other hand. -
Page 29: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a Service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 30: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquires concerning your Tricity Bendix appliance, or further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below;... -
Page 31: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... - Page 32 Tricity Bendix, 55-77 High Street, Slough, Berkshire SL1 1DZ Consumer care telephone number 08705 950950 IMPORTANT NOTICE In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed.
