SIGMA
Sigma H master clock
Installation and start-up instructiond
BODET SA
1 rue du Général de Gaulle
49340 TREMENTINES
Tél: 02 41 71 72 99
Fax: 02 41 71 72 01
www.bodet-time.com
Usine de Trémentines
Système de
Management certifié
Upon receipt, always check the product for damage during shipment. If any is found, you may file a damage claim with the carrier.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sigma H and is the answer not in the manual?

Questions and answers

Summary of Contents for Bodet Time Sigma H

  • Page 1 SIGMA Sigma H master clock Installation and start-up instructiond BODET SA 1 rue du Général de Gaulle 49340 TREMENTINES Tél: 02 41 71 72 99 Fax: 02 41 71 72 01 www.bodet-time.com Usine de Trémentines Système de Management certifié Upon receipt, always check the product for damage during shipment. If any is found, you may file a damage claim with the carrier.

  • Page 2: Table Of Contents

    Table of contents 1) General 2) Safety rules 3) Description 4) Installation 4.1 Mechanical installation 4.2 Electrical connections Connection for D1D2 distribution : Connection of DHF transmitter : 5) Installation examples 5.1 Set the 24V impulse output 5.2 Set the DHF output 5.3 Set a 24V TBT output 6) Keypad: Key functions 7) Main menu programming...
  • Page 3 SIGMA H Installation and start-up instructions...

  • Page 4: General

    CAUTION : Any modification on the product renders the guarantee null and void. Checking the equipment: One SIGMA master clock. This instruction manual. To verify the model of the master clock, SIGMA H press the key.

  • Page 5: Safety Rules

    2) Safety rules • Maintenance of this equipment must be carried out by qualified personnel. • If the SIGMA is connected to the 230 V mains power supply, its installation must comply with the European standard IEC 364 (NFC 15.100 for France). PROTECTIONS : •...
  • Page 6 • IMPORTANT: before any installation, refer to the “technical characteristics” paragraph. • Caution : • In case of replacement of the CR2032 battery, it is IMPERATIVE to respect the polarity following the opposite indications. • There is risk of explosion if the battery is replaced by a battery of incorrect type.

  • Page 7: Description

    3) Description Wall box A) LCD screen B) Keypad (see page 14) C) Alarm indicator light (red LED) D) Mains indicator light (green LED) 19” Rack...

  • Page 8: Installation

    4) Installation 4.1 Mechanical installation Choose a room with low temperature variations away from any source of electrical interference (contactors, motors, etc.). WALL-MOUNTED version: Unscrew the 2 screws on the front, remove the cover (for the lower cover, press on the 2 clips (N) and slide it upwards).

  • Page 9: Electrical Connections

    4.2 Electrical connections Connect the cables (mains power supply, impulse line or AFNOR output and radio synchronisation input, depending on the model) to the corresponding terminal strips as shown in the figure below. See the limit characteristics of these circuits on page 31 (**) 110 to 230VAC or...

  • Page 10: Connection For D1D2 Distribution

    Connection for D1D2 distribution : D1 D2 uses the relays of circuits 1 and 2 To Bodet D1 D2 D1D2 movement. Make a shunt between terminals 1 and 3, 0.75² < cross section of wires <1.5². Circuits must be protected by fuse disconnector or circuit breaker 4A maximum.

  • Page 11: Connection Of Dhf Transmitter

    Connection of DHF transmitter : There are two types of DHF transmitters. DHF transmitter “Time and relays”, reference 907512, for SIGMA master clocks. Transmitter cable 907512 Yellow White Green Brown DHF transmitter “Time”, reference 927230, for master clocks SIGMA, DELTA, ALFA, etc.

  • Page 12: Installation Examples

    5) Installation examples 5.1 Set the 24V impulse output Connect the 24V impulse clock line to the terminals 14 and 15. Switch on the SIGMA. Access to the technician menu (see Impuls 01:MIN 1.2s ú page 21). Access to the menu “Time outputs”. START 00:00 P+ OK Use the navigation keys to : - Select the type of distribution (minute, 1/2 minute, second),...

  • Page 13: Set A 24V Tbt Output

    5.3 Set a 24V TBT output The 24V must be connected to the terminals 14 and 15. Switch on the SIGMA. Enter the technician menu (see page 21). Impuls 01: TBT24V ú Enter the “Time outputs” menu. Use the navigation keys to select : TBT24V. STOP Caution : this output is protected ;...

  • Page 14: Keypad: Key Functions

    6) Keypad: Key functions Keys Functions Menu key. Correction key. Validation key. Navigation keys. Note: exit from the menus is automatic if a key has not been pressed for one minute in the customer menu or for 5 minutes in the technician menu.
  • Page 15 Synoptic diagram of the programming      + Access code Load/save Choice of       the time programming synchronisation (not available)        Time output Put in    ...

  • Page 16: Main Menu Programming

    7) Main menu programming 7.1 Standby state ■ In normal functioning the SIGMA displays the time and date : ó is the radio signal indicator, which 10:54:32 ó flashes if reception is poor. Fri 22 MAY 2014 7.2 User menu To access the user menu, press the menu key Enter the user access code if necessary (see USB transfer...

  • Page 17: Usb Loading And Backup

    7.3 USB loading and backup This menu is visible on the LCD screen of USB transfer the master clock Sigma H but is unused. Add DHF receivers õ In the case of a validation of the item with the key...

  • Page 18: Access Code

    7.5 Access code To enter or remove the SIGMA access code, validate the option with the key, Access code The following screen is displayed : Time and date õ Choose the option you require and validate it Access code: Yes ú with the key.

  • Page 19: Time And Date

    7.6 Time and date Time and date To change the time or the date of the SIGMA, Dynamic reception õ validate the option with the key, Time zone : LONDON ú The following screen is displayed : (GMT + 00:00) You have access to the time zone selection.

  • Page 20: Dynamic Radio Reception

    The languages available are : FRENCH, Language:ENGLISH ú ENGLISH, SPANISH, GERMAN, DUTCH, PORTUGUESE, NORWEGIAN, DANISH, ... 7.9 Version Version To view the version of the SIGMA, validate õ the option with the key, The following screen is displayed : SIGMA H Version V1.1E06 25/04/2016 ok...

  • Page 21: Technician Menu Programming

    8) Technician menu programming The technician menu is accessible via an access code sent to the approved persons. Press one of the navigation keys for a few Enter TECHNICIAN code seconds. **** A code is then requested. The technician code is a fixed code, You then have access to the technician menu with the key.

  • Page 22: Time Synchronisation Menu

    8.1 Time synchronisation menu To configure the time synchronisation of the SIGMA, validate the option in the technician menu with the key, Time synchro The following screen is displayed : Time outputs õ Select the time synchronisation mode from Synchro:EXTERNAL ú the following options: DCF Radio, Minute radio (mode used for countries receiving the DCF radio signal...

  • Page 23: Programmable Time Changeover

    8.1.1 Programmable time changeover This menu can be used to program the summer/winter time changeover dates. It allows you to define the start of the winter Prog. time change:Yesú period and then the start of the summer period. To program the summer/winter time Last Sun OCT.03h ú...

  • Page 24: Setting The Time Base

    8.1.2 Setting the time base This menu can be used to set the drift of the time base. This can be useful when the master clock has no external synchronisation. Drift:+0.0sec/day ú To access this menu, you need to have Time base setting ok selected “None”...

  • Page 25: Time Output Management Menu

    8.2 Time output management menu This menu can be used to view all the time outputs, modify their status (Start/ Stop), configure the DHF distribution in Init mode and configure the “impulse” and “D1D2” distribution. This menu allows you also to configure the impulse output (Impuls 01) to provide TBT 24VDC (1A) power supply.
  • Page 26 Remark: the “D1D2” menu appears only if the relays have been assigned to the D1D2 distribution. Use the key to move on to the next parameter: Choice of impulse length. Minute 24V standard impulse length (factory configuration) of 1.2 seconds variable from 0.5 to 5 seconds, Second 24V standard impulse length (factory configuration) of 0.3 seconds variable from 0.1 to 0.9 seconds, D1D2 standard impulse length (factory configuration) of 6 seconds,...

  • Page 27: Function Setting Menu

    8.3 Function setting menu This menu can be used to define whether the master clock functions as a master or as a secondary clock (slave). It can also be used to activate the backlight of the display screen. To go to the SIGMA function setting menu, Function setting ok validate the option in the technician menu Update syst.

  • Page 28: Cpu Software Download Menu

    8.4 CPU software download menu This menu is visible on the LCD screen of USB transfer the master clock Sigma H but is unused. Add DHF receivers õ In the case of a validation of the item with the key...

  • Page 29: Alarm Messages

    9) Alarm messages By default, the alarm configuration is : - Activated: if an alarm is present, a message is displayed on the readout, - Alarm relay: relay 3 is activated if an alarm is triggered. If an alarm is active, the display alternates 10:54.32 ó...
  • Page 30 Alarm message Meaning The user code has been entered three times incorrectly; the user code keyboard is blocked for 10 minutes. fail. The technician code has been entered three times incorrectly; the tech.code keyboard is blocked for 10 minutes. fail. The lithium battery used to save configuration data is defective;...

  • Page 31: Technical Characteristics

    10) Technical characteristics Designation Characteristics Backup Permanent backup of all parameters in case of mains failure. Automatic resetting of receiver clocks to correct time after mains restoration. Time base Quartz, accuracy 0.1 seconds per day between 20 and 25°. Power supply 115 or 230 V AC ±...
  • Page 32 Wall-mounted : IP41 / Rack : IP 20 Protection index 0 to 50°C Operating temperature By access code Keypad locking WALL-MOUNTED version 19» RACK Version Dimensions Width 220 mm 483 mm (1 width) Height 322 mm 44 mm (1 U) Depth 83 mm 200 mm...

  • Page 33: Appendix: Time Zones Predefined

    11 ) Appendix: Time Zones predefined Time City State -> Summer -> Winter Zone offset time time London, Dublin, England, Ireland, Last Sun. Mar. Last Sun. Edinburgh, Lisbon Scotland, Portugal (01:00) Oct. (02:00) Brussels, Amsterdam, France, Belgium, Last Sun. Mar. Last Sun.
  • Page 34 Time City State -> Summer -> Winter Zone offset time time Los Angeles (Pacific USA, Canada, 2nd Sun. Mar. 1st Sun. Nov. Time), Victoria, Tijuana, Mexico (02:00) (02:00) Mexicali Denver (Mountain Time), USA, Canada 2nd Sun. Mar. 1st Sun. Nov. Edmonton (02:00) (02:00)

  • Page 35: What To Do If

    12 ) What to do if ...? Check that … What to do if ...? Check that … (see page 7 for references) The green LED does not >Check that the mains is present (D). >Check that the terminal strips (K) are correctly positioned on light up when the unit is the printed circuit.
