Triarch Mini Pendant 31609 1lt Assembling Instructions

1lt mini pendant
Hide thumbs


Advertisement

1. Unpack the carton and place the fixture on a flat surface. Attention: All necessary hardware and loose
components have been verified for this fixture and are packed inside. Do not discard inner packing until you
have inspected it thoroughly.
2. Place the GLASS (C), GLASS HOLDER (D) through the socket onto the BOBECHE (B). Thread the SOCKET
RING (E) onto the socket. Secure the glass by the SOCKET RING (E).
3. Measure the height from hanging fixture to your ceiling. Cut the excess chain and wire to fit the height. Put the
fixture onto the chain
4. Follow the wattage label on the SOCKET RING (H) and install proper bulb (no provided) onto the socket.
5. For mounting and wiring step please follow the mounting instruction sheet enclosed.
30609 1lt Mini Pendant Assembling Instruction
BODY (A)
BOBECHE (B)
GLASS (C)
GLASS HOLDER (D)
SORCKET RING (E)
