Triarch Indoor Lighting 33165 Assembly Instructions

• Hanging Fixture

This lamp uses sixteen (16 ) 60-watt
maximum Type A bulbs (Not included).

Cleaning Instructions

Do not use polish or cleaners.
Wipe clean with a soft cloth.
1. Thread the Loop ( A) to the nipple of the Tube(B) until tighten.
2. Attach the Cap(C) to the Nipple (D) then secure by Tube (B).
3. Place Glasses(F) over Sockets (G) and secure by Socket Rings (E).
4. Thread the Nipple ( I ) on Finial (J) to the Bottom Coupler (H) until tighten.
5. Install the light bulb (not provided) in accordance with the fixture specification.
6. Restore electricity and check the operation of your new light fixture.
Typical Assembly Time: 15 minutes
Assembly Instructions
A
33165
