• Hanging Fixture
This lamp uses Three (3) 100-watt
maximum Type A bulbs (Not included).
Cleaning Instructions
Do not use polish or cleaners.
Wipe clean with a soft cloth.
1. Thread the Loop ( A) to the nipple of the Tube(B) until tighten.
2. Attach the Cap(C) to the Nipple (D) then secure by Tube (B).
3. Thread the Nipple (G ) to Bottom Coupler (E) then screw the Hex Nut(F) until tight. (Nipple may
require adjustment)
4. Attach the Tube (H), Metal Cap ( I ) , Glass Cap(J), Glass (K) and Washer (L) then secure by Hex
Nut(M).
3. Attach the Cap (N) to the Glass (K) and secure by Finial(O).
5. Install the light bulb (not provided) in accordance with the fixture specification.
6. Restore electricity and check the operation of your new light fixture.
Typical Assembly Time: 15 minutes
Assembly Instructions
A
33162
