Konica Minolta bizhub C652 Replacement Instructions Manual

Cms replacement instructions 1. drum unit/k, ozone filter, toner filter
Hide thumbs Also See for bizhub C652:

Advertisement

Quick Links

CMS REPLACEMENT INSTRUCTIONS
(Customer Maintenance Support)
CMS REPLACEMENT INSTRUCTIONS
1. Drum unit/K, Ozone filter, Toner filter

Advertisement

loading
Need help?

Need help?

Do you have a question about the bizhub C652 and is the answer not in the manual?

Questions and answers

Related Manuals for Konica Minolta bizhub C652

Summary of Contents for Konica Minolta bizhub C652

  • Page 1 CMS REPLACEMENT INSTRUCTIONS (Customer Maintenance Support) CMS REPLACEMENT INSTRUCTIONS 1. Drum unit/K, Ozone filter, Toner filter...
  • Page 2 CMS Instructions for Replacement safely, and also be careful not to get it lost. Should it get lost, contact our service representative. Registered trademark • bizhub is a registered trademark of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. Copyright © 2009 KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.

  • Page 3: Table Of Contents

    CONTENTS For your safe operation ....................S-1 Meaning of the graphic expression ................S-1 Examples of graphic symbols ..................S-1 Caution notice/Caution label ..................S-6 REPLACEMENT INSTRUCTIONS ..................1...

  • Page 4: For Your Safe Operation

    For your safe operation For your safe operation For your safe operation, the following are the descriptions of the notices and requests that you have to follow when replacing parts. Be sure to read them carefully before conducting any part replacement operation. •...
  • Page 5 For your safe operation Operations before replacing any part: CAUTION • When conducting a part replacement operation, be sure to get guidance from the customer engineer. And also, read the CMS Replacement Instructions carefully before con- ducting a part replacement operation by following the pre- scribed procedure and using tools also prescribed.
  • Page 6 For your safe operation CMS part replacement operation: WARNING • Make sure the wiring cannot come into contact with sharp edges, burrs, or other pointed parts. Current can leak, leading to a risk of electric shock or fire. • Make sure that all screws, components, wiring, connec- tors, etc.
  • Page 7 For your safe operation When any abnormal condition is found: WARNING • When the copier gets hot abnormally, or when it gives out smoke, a foul smell or abnormal noise, turn off the power switch at once. And then be sure to unplug the power cord from the power outlet and contact our service technician.
  • Page 8 For your safe operation Grounding: WARNING • Connect the power cord to an electrical outlet that is equipped with a grounding terminal.

  • Page 9: Caution Notice/Caution Label

    For your safe operation Caution notice/Caution label For this copier, there are the caution notices or labels for safety operations provided at the locations as shown below. Be sure to take every care to avoid any accidents while in the part replacement operation.
  • Page 10 Drum unit/ K, Ozone filter, Toner filter REPLACEMENT INSTRUCTIONS 2009.07 Ver. 2.0...

  • Page 11: Replacement Instructions

    Drum unit/K, Ozone filter, Toner filter replacement instructions REPLACEMENT INSTRUCTIONS Drum unit/K Removal procedure 1. Open the lower front door [1]. A0P0F2C555DA 2. Release the securing levers [1] for the waste toner box, and then remove the waste toner box [2]. A0P0F2C514DA...
  • Page 12 Drum unit/K, Ozone filter, Toner filter replacement instructions 3. Loosen the shoulder screw [1], and pull out the drum unit/K [2]. A0P0F2C523DA 4. Hold the fixed lever [1] for the drum unit/K at two positions, and remove the drum unit/K [2] while loosening the fixed lever.
  • Page 13 Drum unit/K, Ozone filter, Toner filter replacement instructions 3. Put the drum unit/K on the develop- ing unit/K. NOTE • Do not tilt the drum unit/K when putting it on the developing unit/K. (Keep the drum unit/K level.) • Position the drum unit/K so that part A of the drum unit/K is inserted into part B of the developing unit/K.
  • Page 14 Drum unit/K, Ozone filter, Toner filter replacement instructions 5. Secure the drum unit/K [1] to the developing unit/K with the two levers [2]. NOTE • Push the front and back levers in the direction of the arrow at a time to secure the drum unit/K.
  • Page 15 Drum unit/K, Ozone filter, Toner filter replacement instructions 7. Reinstall the waste toner box [1]. A0P0F2C513DA 8. Close the lower front door [1]. A0P0F2C556DA 9. Proceed to replace the ozone filter. See P.6...
  • Page 16 Drum unit/K, Ozone filter, Toner filter replacement instructions Ozone filter 1. Remove the ozone filter [1], and replace it. A00JF2C527DA 2. Proceed to replace the toner filter. See P.6 Toner filter 1. Remove the toner filter [1], and replace it. A0P0F2C520DA...
  • Page 17 MANUFACTURER TOKYO JAPAN Copyright 2009...
