- Page 1 Domestic Hot Water Cylinder With Ch Buffer Tank SWVPC - 200/100 Assembly and operating manual...
- Page 2 Safety instructions Read and strictly follow this installation and operating instructions to ensure a long life and reliable cylinder operation. The manufacturer of this cylinder will not be liable for any damages due to the failure to follow the installation and operation instructions. The cylinder must not be installed in rooms where the temperature may drop below 0°C.
- Page 3 Description of device Cylinder SWVPC is a device with double tank intended to heating medium system with heat pump. The upper tank is enamelled with double heating coil, intened to prepare domestic hot water. In the lower part, there is a buffer with unenamelled tank, anti-corrosion inhibitor protected for transport.
- Page 4 Connection to the water system Please follow water connection instructions below: install the T-connection with 6 bar* safety valve and the drain valve to the fitting of cold water inlet [ZW]. It’s forbidden to install a cut-off valve (or any flow reducer) between the tank and the safety valve and on its outlet.
- Page 5 Cylinders’ construction SWVPC-200/100 ø695 (200/100) Dimensions SWVPC CW 3/4” ZWEZ 1” C 3/4” ZW 3/4” 1156 ZG 1” 1299 PG 1” 1455 S 1/2” 1610 [1] - lower lid ZW - cold water [2] - thermal insulation CW - hot water...
- Page 6 Cylinder emptying In order to empty the cylinder: • turn off the valves which connect cylinder with central heating system, • turn off the valves which connect cylinder with PC circuit, • turn off the valve to connect the cold water inlet with cylinder, •...
- Page 7 Technical data Domestic Hot Water Cylinder SWVPC Storage capacity Rated pressure Rated temperature °C Surface area of heating Capacity of coil Power of coil 70* / 22** Efficiency of coil 1800* / 550** Weight (without water) Magnesium anode M8 ø40 heating water temp./ supply water temp./ domestic water temperature;...
- Page 8 KOSPEL S.A. 75-136 Koszalin, ul. Olchowa 1 tel. +48 94 31 70 565 serwis@kospel.pl www.kospel.pl...
