2. Apply 4 strings of threadlocker vertically on the end
cap threads. Make sure that you use the correct
threadlocker type, refer to
threadlocker type on page 9 . Make sure that no
threadlocker goes into the vibrator head.
3. Put oil into the end cap. Keep the end cap vertical
and make sure that no oil goes on the end cap
threads.
4. Keep the end cap vertical and install the stator tube.
Lubrication
Vibrator head
3
Shell T46, cm /cl
Vibrator head
Shell Alvaia G3, 2 needle bear-
3
cm /cl
1 needle bearing
Tightening torque and threadlocker
type
B
A
Vibrator head
Threadlocker
AX36-AX65
LOC-
End cap (A)
TITE
Screw (B)
LOC-
Coupling (C)
TITE
Thrust screw LOC-
1
(D) TITE
LOC-
Screw (E)
TITE
1
The thrust screw holds the ground cable and seals the vibrator head. If the thrust screw is not sealed correct-
1006 - 002 - 27.03.2020
Tightening torque and
AX36
5/0.5
AX90
7/0.7
ings
1.25/0.12
B D
C
AX36
170
® ™
243
N/A 5
120
® ™
243
N/A
® ™
243
N/A
® ™
243
ly, oil can leak from the vibrator head.
5. Tighten the end cap to the specified torque, refer to
Tightening torque and threadlocker type on page
9 .
AX40 AX48
5/0.5 10/1
E
Tightening torque, Nm
AX40 AX46
170 350
5
120 200
N/A N/A
N/A N/A
CAUTION: Do not tilt the end cap when
you install the stator tube. If oil goes on
the end cap thread, the threadlocker
does not lock the thread.
AX56
15/1.5
AX56
520
8 8
250
N/A
N/A
AX65
20/2
AX65
750
20
250
N/A
N/A
