ASSEMBLY AND MOUNTING INSTRUCTION

For 31910/1
Please read the Assembly lnstruction sheet carefully before proceeding.Carefully unpack and
identify all parts prior to building the unit. Each part is identified on the drawing for reference.
DO NOT DISCARD THE ORIGINAL PACKAGING. If after careful inspection and you must return the item
for any reason. Please repack the unit using the original carton and inserts.
STEP 1:Unpack all the parts and classify Them according to the illustration shown at
the side. Place the parts on a scratch free
surface;
Bul b
STEP 2: Make sure the power is turned off at
the wall sutlet box where the fixture is to be
installed. Secure the cross bar to the wall
junction box screws;
f abri c shade
STEP 3: Use the wire nuts to connect the
positive and negative wires. Connect the
ground wire to the junction box ground port;
STEP 4: Secure the fixture to the wall outlet
box using two ball nut;
STEP 5: Install Candle Cover and fabric shade;
Bottom Cap
STEP 6: Install the correct bulb (not provided);
Fi xture
U ni versal m ounti ng bar
..
