ASSEMBLY AND MOUNTING INSTRUCTION

For 31900/1
Please read the Assembly lnstruction sheet carefully before proceeding.Carefully unpack and
identify all parts prior to building the unit. Each part is identified on the drawingfor reference.
DO NOT DISCARD THE ORIGINAL PACKAGING. If after careful inspection and you must returnthe item
for any reason. Please repack the unit using the original carton and inserts.
STEP 1:Unpack all the par ts and Classify
them according to the illustration shown
at the side.Place the par ts on a scratch
-free surface;
STEP 2: Make sure the power is tur ned Off
Bulb
at the wall outlet box where the fixture is
to be installed.Secure the cross bar to the
Socket Collar
wall junction box using the junction box
Socket Ring
screws;
STEP 3: Use the wire nuts to Connect the
positive and negative wires. Connect the
Ground wire to the junction Box ground
por t;
STEP 4: Secure the fixture to the Wall
outlet box using ball nut;
STEP 5: Install the glass shades and
Secure Them with the socket rings and
socket collars;
STEP 6: Install the correct bulb (not
provided);
