Triarch 31743 Assembly Instructions

1. Before beginning the assembly, carefully unpack and identify all parts referring to the illustration.
2. Unravel the supply power and ground wires and pass the holes of column. Thread the bottom of
column into the coupling at the top of fixture body. Hand tightens until snug.
3. Locate the scroll. Attach the scroll to the fixture body and the column with ball nut and ball stud as
shown in the illustration.
4. Carefully place the glass over the socket and secure with the socket ring by sleeve wrench as
shown in the illustration. Hand tightens until snug.
5. Install proper bulbs (not provided) to the sockets referring to the markings and labels on fixture for
maximum wattage.
6. Restore power to the installation point ON. Retain this sheet for future reference.
IF IN DOUBT ABOUT ELECTRICAL INSTALLATION,
CONSULT A LICENSED ELECTRICIAN!
ASSEMBLY INSTRUCTIONS FOR 31743
Ball stud
Scroll
Ball nut
Sleeve wrench
Socket ring
Column
Glass
Fixture body
