- Page 1 Frequency converter VAU4/3 with adapter (order no. 59630241115 / standard) Version 1.3 www.becker-international.com...
- Page 2 1 Next, fasten the assembled cabling to the adapter plate (order no. 00360341100) using two M3 screws (order no. 94630400000) as shown in figure 2. Note: Using the adapter plate will increase the entire height by 4cm. figure 2 www.becker-international.com...
- Page 3 Carefully place the adapter plate and cabling onto the motor and fasten them using the three M5 screws (order no. 94530800000) as shown in figure 4. When placing the adapter plate onto the motor, ensure that the converter jack and motor plug mate together properly. Furthermore, be sure not to damage the motor cable. figure 4 www.becker-international.com...
- Page 4 94531500000), fasten the converter to the adapter plate (figures 5 and 6). M5 screws figures 5 + 6 3 2 1 conductor numbers figure 7 Connect the cables as shown in figure 7. When assembling the cover, make sure that the ground cable is connected to the cover. www.becker-international.com...
- Page 5 To install the mounted connector (order no. 74200870000), first remove the threaded connection on the left (figure 11). Screw the installation plug now into the enclosure from the outside. Warning: Do not forget the sealing ring under the installation plug! figures 11 + 12 www.becker-international.com...
- Page 6 Strip the cable ends, tin the wire ends and connect to the module without the wire end ferrules as shown in figure 13. figure 13 Note The cable ends may be stripped only very short. (Do not forget the tinning!). The screws should be tightened very carefully but firmly nevertheless. (figure 14) figure 14 www.becker-international.com...
- Page 7 To configure the converter, use KombiTool 6.2 in the accustomed manner. You only have to load one de- scription file and create one new text file. The data line is connected to terminals 4 (RS485 A) 5 (RS485 B) of the converter. www.becker-international.com...
