  • Page 1 Original Instructions 5012207 Originally written in UK English Date Published:14/06/2019...
  • Page 2 Technical Helpline, the number of which can be found on the Evolution Power Tools website. We operate several Helplines throughout our worldwide organization, but Technical help is also available from your supplier.
  • Page 3 www.evolutionpowertools.com Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Fig. 12...

  • Page 4: Metric Imperial

    SPECIFICATIONS R355CPS MACHINE METRIC IMPERIAL Motor (UK/EU) 220V-240V ~ 2200W 50Hz Motor (UK) 110V ~ 50Hz 1600W Motor (USA) 120V ~ 60Hz Motor (AUS) 240V ~ 50Hz 2200W Speed (No Load) @ 110V 1550 min 1550 rpm Speed (No Load) @ 120V...

  • Page 5: Polarized Plug

    Warning adopted. LABELS & SYMBOLS (1.8) WARNING: Do not operate this machine (RCM) Regulatory Compliance Mark if warning and/or instruction labels are missing for electrical and electronic equipment. or damaged. Contact Evolution Power Tools for Australian/New Zealand Standard replacement labels.
  • Page 6 WARNING: This product has been designed to 2) General Power Tool Safety Warnings (2.3) [Electrical Safety] be used with special Evolution blades. Only use accessories designed for use in this machine a) Power tool plugs must match the outlet. and/or those recommended specifically Never modify the plug in any way.
  • Page 7 Use of the Use only Evolution carbide tipped blades when power tool for operations different fromthose cutting woods, metals and plastics or Evolution intended could result in a hazardous situation.
  • Page 8 www.evolutionpowertools.com rotating wheel. If kickback occurs, it will the wheel thus reducing the possibility of wheel breakage. propel the cutting unit upwards toward the f) The outside diameter and the thickness of operator. your accessory must be within the capacity c) Do not attach a saw chain, woodcarving rating of your power tool.

  • Page 9: Additional Warnings

    www.evolutionpowertools.com 5. Keep children away. All visitors should be the wheel to climb out or kick out. Abrasive wheels may also break under these conditions. kept safe distance from work area. 6. Make workshop child proof with padlocks, Kickback is the result of power tool misuse and/ or incorrect operating procedures or master switches, or by removing starter keys.

  • Page 10: Replacement Blades

    For instructions on how to identify the batch NOTE: This machine is supplied with 2 accessories. code, please contact the Evolution Power Tools The 8mm hex key should be kept in the dedicated helpline or go to: tool storage located in the front of the base when www.evolutionpowertools.com...

  • Page 11: Machine Overview

    www.evolutionpowertools.com MACHINE OVERVIEW LOWER BLADE GUARD 13. CARBON BRUSHES ACCESS CAP UPPER BLADE GUARD 14. ON/OFF TRIGGER SWITCH FRONT SWIVELLING VICE JAW 15. CARRY HANDLE REPOSITIONABLE REAR VICE JAW CUTTING HANDLE CUTTING HEAD HOLD DOWN PIN TRAVEL STOP ADJUSTMENT SCREW WORK BENCH MOUNTING HOLES X4 BLADE CHANGE HEX KEY 10.
  • Page 12 • Place the vice jaw into its new service position. • Refit the fence securing bolts, washers and REMOVING OR INSTALLING A BLADE spacer. WARNING: Only use genuine Evolution blades CHIP COLLECTION designed for this machine - see page 10 A specially shaped steel shield (Fig. 10)

  • Page 13: Operating Advice

    NOTE: As all operating environments are unique • Ensure that the ‘cut-off’ piece cannot become and diverse, Evolution Power Tools offers the ‘jammed’ in any other part of the machine. following general advice on safe operational • Do not use these saws to cut small pieces.

  • Page 14: Maintenance And Adjustments

    www.evolutionpowertools.com • Reduce the pressure as the blade begins to Used but serviceable brushes can be replaced, exit the material. but only as long as they are returned to the same position, and inserted the same way round, as they On completion of a cut release the ON/OFF were removed from the machine.

  • Page 15: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY The manufacturer of the product covered by this Declaration is: UK: Evolution Power Tools Ltd. Venture One, Longacre Close, Holbrook Industrial Estate, Sheffield, S20 3FR. FR: Evolution Power Tools SAS. 61 Avenue Lafontaine, 33560, Carbon-Blanc, Bordeaux, France.
  • Page 16 Total Tools (Importing) Pty Ltd Evolution Power Tools SAS 20 Thackray Road 61 Avenue Lafontaine Port Melbourne 33560, Carbon-Blanc Vic 3207 Bordeaux T: 03 9261 1900 T: +33 (0)5 57 30 61 89 Evolution Power Tools Ltd Evolution Power Tools LLC...

This manual is also suitable for:

R355 cps083-0001083-0002083-0004083-0003083-0006
