TRENDnet TEG-2248WS Specifications

FEATURES
• 48 x 10/100Mbps Auto-MDIX Fast Ethernet ports
• 4 x 10/100/1000Mbps Auto-MDIX Gigabit ports
• 2 x 1000Base-SX/LX Mini-GBIC slots (shared with 2 Gigabit ports)
• 17.6GBps switching capacity
• IEEE 802.3x Full Duplex Flow Control and Back Pressure
• IEEE 802.3ad Port Trunk
• IEEE 802.1D Spanning Tree Protocol
• IEEE 802.1p QoS
• IEEE 802.1X Authentication and SNMP v1 support
• Supports port based IEEE 802.1Q VLAN Tag and Asymmetric VLAN
• Store and Forward switching method
• Integrated address look-up engine with an 8K absolute MAC address table
• Supports 128K bytes RAM for data buffering
• Easy configuration via Web browser
• Front panel diagnostic LEDs
• Standard 1U (19") rackmount size (rackmount kit included)
• 3-Year Limited Warranty
48-Port 10/100Mbps Web Smart Switch
with 4 Gigabit Ports and 2 Mini-GBIC Slots
TEG-2248WS [
B1.0R]
The 48-Port 10/100Mbps Web Smart Switch with 4 Gigabit Ports and 2
Mini-GBIC Slots (model TEG-2248WS) delivers a 17.6Gbps switching
capacity with managed layer 2 features at a reduced cost. Support for
SNMP v1, 802.1X, STP, 802.1Q VLAN, QoS, IGMP snooping,
Broadcast Storm Control and port Trunking provides a cost effective,
scalable and secure backbone switch solution for SMB networks.
SNMP support enables the switch to provide valuable status and event
information, saving system administrators time and resources. Connect
a fiber network to the shared Mini-GBIC slots and network servers and
switches using the Gigabit RJ-45 ports. Access the Web-browser
management interface and segment up to 256 Virtual Local Area
Networks, manage network priority with 802.1p support and dedicate
bandwidth with port-based Trunking.
gigabit
TEG-2248WS
rev: 06.29.2010
