FlexWave
Flexible Outdoor Coverage and Capacity

Specifications

RF SpeciFication
Supported Frequency Blocks:
Bandwidth:
Frequency Band Supported:
Digital Simulcast:
Diversity Receive:

pRopagation Delay

System Delay:
Delay Management:
noiSe FigURe
noise Figure:
input ip3:
optical SpeciFicationS
optical Budget:
Digital transport Rate:
oUtpUt poweR
output power per Band:
ReMote Unit enViRonMental SpeciFicationS
outside ambient
temp Rating:
Storage temperature:
Humidity:
lightning protection:
ReMote Unit
enclosure:
Mounting:
Dimensions (H x w x D):
Volume:
weight:
cooling:
optical connectors:
HoSt Unit
Mounting:
Dimensions (H x w x D):
weight:
ReMote Unit poweR ReqUiReMentS
power Supply:
Battery Backup:
power consumption:
HoSt Unit poweR ReqUiReMentS
power Source:
power consumption:
element Management
embedded eMS:
SnMp Based Management:
Note: Unless noted otherwise specifications are typical and subject to change
w w w . a d c . c o m
Universal Radio Head
™
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
1-3 per Remote Unit; 1-8 per Host Unit
1.5 to 35 MHz non-contiguous
800 Cellular, E-SMR 800/900,
1900 PCS 1700/2100 AWS
700, 1800 and 2500MHz (Future Releases)
Up to 8:1 Single Host (can daisy chain Host for higher simulcast)
Yes (Optional)
<12 microseconds
Digital (Manual or Automatic)
<5 dB
>-8 dBm
10 dB (Standard); 26 dB (Optional)
3.072 Gbps
38 dBm (6.5 Watts) Cell/SMR
43 dBm (20 Watts) PCS
43 dBm (20 Watts) AWS
-40°C to +50°C
-40°C to +70°C
10% to 90% non-condensing
20kA IEC 1000-45 8/30 µs Waveform
IP-65
Wall, Pole, Inside Pole, Strand, and Vault
29.38" x 16.45" x 15.6"
3.66 Cubic Feet
≤200 Pounds (No one component >80 lbs.)
Passive Convection
Sealed Proax
19- and 23-inch rack
5.25" x 19" x 19" (3 RUs)
<25 Pounds
100-240 VAC, 50-60 Hz
Yes (External)
~1000 Watts (Fully loaded 20 W doors)
24 to 48 VDC
~250 Watts (Fully loaded with 8 DARTs)
Yes
Yes
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1 7
