- Page 1 Quick Installation Guide TEW-430APB...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English ... 1. Before You Start 2. Install Hardware ... 3. Configure the Access Point ... Troubleshooting ... Version 09.27.2007... -
Page 3: Installation Requirements
54Mbps 802.11g Wireless LAN Access Point Workstation with Wireless PCI Adapter (TEW-423PI) Internet Cable/DSL Modem Package Content TEW-430APB Quick Installation Guide User’s Guide CD-ROM External Power Adapter 1 x 2dBi Detachable Antenna (TEW-430APB) Wireless PC Card Cable/DSL 4-Port Firewall Router... -
Page 4: Hardware Installation
Note: Locate an optimum location for the Access Point. The best place for the Access Point is usually at the center of your wireless network. Please connect the computer configuring the TEW-430APB to the same switch/hub. 1. Connect a RJ-45 cable from the... -
Page 5: Configure The Access Point
3. Configure the Access Point Note: It is recommended that you configure the Access Point from a wired computer. Before the Access Point can be configured, a Static IP address must be assigned to your computer's network adapter in the subnet of 192.168.1.x. - Page 6 4. Click Next. 5. Enter a new password for your Access Point, verify the new password, and then click Next. (If a new password is not entered, the default password admin will be used. 6. Enter a SSID for your Access Point and then click Next.
- Page 7 7. Enable Encryption if needed and then click Next 8. Click Restart. 9. Click Close. Your installation is now complete. For detailed information regarding the TEW-430APB's configuration and advanced settings, please refer to the Troubleshooting section, User's Guide CD-ROM, or TRENDnet's website at http://www.trendnet.com. English...
-
Page 8: Troubleshooting
I typed http://192.168.1.100 in my Internet Browser's Address Bar, but an error message says “The page cannot be displayed.” How can I get into the TEW-430APB's web configuration page? First, check your hardware settings again by following the instructions in section 2. - Page 9 15 seconds, then plug the power back in. Third, contact the manufacturer of your wireless network adapter. Make sure the wireless network adapter is configured with the proper SSID. The default SSID of the Access Point is TRENDnet. If you still encounter problems or have any questions regarding the TEW-430APB, please contact TRENDnet's Technical Support Department.
- Page 10 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
-
Page 11: Product Warranty Registration
English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register 20675 Manhattan Place Torrance, CA 90501 Copyright ©2007. All Rights Reserved. TRENDnet.
