Related Manuals for TrekStor 115
Summary of Contents for TrekStor 115
- Page 2 TrekStor...
- Page 3 Features ......TrekStor i.Beat 115 2.0 controls ... . .
- Page 4 Creating MP3 files ..... Logging off from your computer ... . . Updating the firmware for your TrekStor i.Beat 115 2.0...
- Page 5 FAQ ......A.1 Support and contact ....A.2 Liability .
- Page 7 Congratulations on your purchase of the TrekStor i.Beat 115 2.0 . We are sure you will enjoy countless hours of listening pleasure. The TrekStor i.Beat 115 2.0 is a high-quality MP3 player with numerous functions for enjoying music at home or on the go. Please read the instructions in this manual before using the player.
- Page 8 ˆ Large LCD ˆ M3U playlist function ˆ Line-in recording ˆ Dictation function ˆ Folder navigation ˆ And much more...
- Page 9 Eye for neck strap Microphone Volume button (to the left) Fast forward button button (Play/Pause/OK/On/Off) Rewind button Volume button (to the right) Headphone jack Battery cover USB connector button (key lock) button (menu) button / Recorder...
- Page 10 The TrekStor i.Beat 115 2.0 has only a few buttons to make operation as easy as possible. There are more functions than buttons, however. How long you hold down a button determines which function you want to be carried out.
- Page 11 To switch off your TrekStor i.Beat 115 2.0 , hold down the but- ton for at least two seconds. The TrekStor i.Beat 115 2.0 switches off automatically. To enable the key lock, push the button to the right. The key lock icon appears in the upper right of the display next to the battery icon.
- Page 12 Press and release the buttons to adjust the volume gradually. Hold down the buttons to adjust the volume continuously. The TrekStor i.Beat 115 2.0 makes managing music files easy. You can store your data in different folders. You can use the folder navigation function to select specific subdirectories and files.
- Page 13 . You will be asked whether you are sure you want to delete the file. Select to delete the file. Your TrekStor i.Beat 115 2.0 allows you to continuously repeat an excerpt of a track. To do so, while the track is playing, press to set the beginning of the segment you want to repeat point.
- Page 14 This mode is also referred to as M3U mode or Playlist mode since it uses Winamp playlists in M3U format. Create a Winamp playlist of MP3 files on your TrekStor i.Beat 115 2.0 to define the order in which tracks are a popular MP3 player that can be downloaded free of charge from...
- Page 15 Save the playlist directly to your TrekStor i.Beat 115 2.0 . The available playlists are then displayed in M3U mode. Select a playlist to play the tracks in the defined order. Go to the main menu. Use the and press to confirm your selection.
- Page 16 Connect an external source such as a CD player to the headphone jack. Press the button on your TrekStor i.Beat 115 2.0 as you start the external source. appears on the display. Recording begins, and the display indicates the length of the previous recording.
- Page 17 Select and press ˆ : Plays all tracks in order. ˆ ˆ : Repeats all tracks in the current folder. ˆ ˆ : Plays all tracks in random order. ˆ : Plays the first 10 seconds of all titles in succession. Go to the main menu.
- Page 18 Press to confirm your selection. Go to the main menu. Use the buttons to select and press to confirm your selection. In the following submenu, you can adjust many of the TrekStor i.Beat 115 2.0 settings to your needs:...
- Page 19 2.0 switches off automatically after selected period. switches off the automatic off feature when the player is not in use. ˆ i.Beat 115 2.0 backlight to remain on after the last button is pressed. : Change the display contrast. ˆ...
- Page 20 ˆ Microsoft Windows ˆ CD-ROM drive ˆ Pentium 200MHz ˆ RAM 32MB (Windows ME, 2000) - 64MB (Windows XP) ˆ USB port 98/ME/2000/XP...
- Page 21 ˆ Restart your computer. A driver is not required to log your TrekStor i.Beat 115 2.0 onto Win- dows ME/2000/XP systems. However, you must install the current Ser- vice Pack version (currently SP4 for Windows 2000, and SP2 for Win- dows XP) to connect your TrekStor i.Beat 115 2.0 .
- Page 22 Once your TrekStor i.Beat 115 2.0 is connected to your computer, it runs like a normal hard disk. The device is automatically assigned its own drive letter. You can drag and drop to copy, move and delete any type of data on your device in Windows Explorer. Note: Your TrekStor i.Beat 115 2.0 only supports the FAT file system, not FAT32 or NTFS.
- Page 23 Once the MP3 files have been created, you can play the tracks on your computer (with Windows Media Player, for example). You can also copy the MP3 files right onto your TrekStor i.Beat 115 2.0 and play them from there.
- Page 24 Windows 98 users must use the to log off the Trek- Stor i.Beat 115 2.0 . In the , open left-click to select the TrekStor i.Beat 115 2.0 . Click . You can now disconnect your TrekStor i.Beat 115 2.0 from the USB connec- tor.
- Page 25 See the TrekStor website for the current version of firmware for your TrekStor i.Beat 115 2.0 . Download the firmware and save it to your Unpack ALL files and copy them to the home directory of your TrekStor i.Beat 115 2.0 . Disconnect your TrekStor i.Beat 115 2.0 from your PC ( section 3.6).
- Page 26 3.2. ˆ The firmware has been damaged. To solve this problem, follow these steps: Remove the battery. Connect your TrekStor i.Beat 115 2.0 to your computer and hold down the button for approximately 3 seconds. hold button to...
- Page 27 Your TrekStor i.Beat 115 2.0 should appear in ’My Computer’ as a new drive. Update the firmware as described in sec- tion 4.1. the exact number of bytes available. ˆ Indications in ’MB’ are always approximate since there is general confusion as to whether 1 MB = 1000 KB or 1 MB = 1024 KB (and whether 1 KB = 1000 bytes or 1 KB = 1024 bytes).
- Page 28 The manufacturer only guarantees the suitability of the product for its intended use. TrekStor and its suppliers shall not be liable for loss of data that occurs during use or due to the use of the device or for consequences thereof. TrekStor shall under no circumstances be liable for direct, incidental...
- Page 29 Under no circumstances can claims that exceed the purchase price of the product be asserted. TrekStor reserves the right to continuously improve the product. All modifications may be made without describing them in this manual. The information contained in this manual must therefore not correspond to the current technical design.
- Page 30 ˆ Never place the device near other electrical devices or equipment such as televisions, radios and speakers since this could affect the operation of the other devices. ˆ Never place the device near sources of magnetic interference such as computer monitors, televisions and speakers.
- Page 31 This product is subject to the legal warranty periods for manufacturing faults and defects. Warranty contents: 1. If a malfunction due to faulty manufacturing should occur, TrekStor will repair or replace the faulty product at its discretion. 2. The following repairs are not included in the warranty and must be undertaken at the user’s expense:...
- Page 32 To assert a claim on the warranty, contact your local shop where you purchased the device. You must present your sales slip. The retailer will then perform services justified by the warranty after consultation with the TrekStor service team. Do not send any products directly to TrekStor. Any such shipments will be processed.
- Page 33 TrekStor TrekStor GmbH & Co. KG TrekStor i.Beat 115 2.0 Manual ib115-2-AT-V2.1-EN-050617b...
