Summary of Contents for Transystem DVB-T
-
Page 1: User Manual
DVB-T USB SET-TOP BOX User Manual Version: 1.0 (February 2005) TRANSYSTEM INC. No.1-2 Li-Hsin Rd.I Science-Based Industrial Park, Hsinchu, Taiwan Tel:+886-3-5780393 Fax:+886-3-5784111 e-mail: sales@transystem.com.tw website: www.transystem.com.tw... -
Page 2: Table Of Contents
Table of Contents Chapter 1 DVB-T USB SET-TOP BOX Introduction ...…...……...3 1.1 Introduction ...……... 3 1.2 Package Content ...….…... 3 1.3 System requirements ...…...3 1.4 Features ...…...4 1.5 Hardware specification……………………………………………….…….…...4 Chapter 2 Installation Procedure ...…...….…...5 Chapter 3 System Setup ...……...12 3.1 How to scan ...…...…..….12... -
Page 3: Chapter 1 Dvb-T Usb Set-Top Box Introduction
1.2 Package Content △ DVB-T USB SET-TOP BOX x 1 △ Quick Installation Guide x 1 △ USB Cable x 1 △ DVB-T Active Antenna x 1 △... -
Page 4: Features
MPEG-II Software Decoding △ Note: The Digital Radio mentioned here is not the same with DAB (Digital Audio Broadcasting), it means the audio broadcasting by the DVB-T content provider. Note: * Depends on Content Provider 1.5 Hardware Specification Support DVB-T(EN300744) △... -
Page 5: Chapter 2 Installation Procedure
Note1: The following installation is operated under Windows 2000. (Procedures are the same in Windows XP) Note2: Be sure the DVB-T USB SET-TOP BOX is connected to your PC when you are installing the software. Note3: After connecting DVB-T SET-TOP BOX to your computer, a pop-up window saying “Found New Hardware Wizard”... - Page 6 Execute the “Setup.exe” program from the CD. The InstallShield Wizard will check the operating system version first. Please follow the directions after it finishes checking. B. Click “Next” to continue. C. Choose “I agree….” and click “Next” to continue.
- Page 7 D. Enter your user information and click “Next” to continue. E. Please input 16 serial numbers and click “Next” to continue. (Serial number can be found on the software CD label)
- Page 8 F. Please read the information and click “Next” to continue. G. Please select the user interface language that you want to install and click “Next” to continue. H. Select an installation folder and click “Next” to continue.
- Page 9 (Or click “Change” to switch to an existing folder) I. Select a shortcut folder and click “Next” to continue.
- Page 10 J. Please click “Next” to process with installation K. Restart the computer and make sure the DVB-T USB SET-TOP BOX is connected to your computer correctly. Please wait 2-3 minutes for the system to find the device. The DVB-T USB SET-TOP BOX is now successfully installed.
- Page 11 L. Click “Finish” to complete the installation. Note: A dialog saying “Digital Signature Not Found” might appear to warn you that the device hasn’t got Microsoft Digital Signature. Select “Yes” to continue the installation, the software has been tested and proved to work correctly with Windows.
-
Page 12: Chapter 3 System Setup
Chapter 3. System Setup How to scan Before watching or listening to TV/Radio, start “Scan Channel” and choose one of the four channel scanning methods (including “Country/Region”, “All”, “Range”, and “Single”) to conduct program scanning. The scan results will be shown on the TV and Radio lists, you can also save the list for future use. - Page 13 Buttons Play – TV, files Stop – TV, recordings, files, TimeShift Pause – TV, recordings, files, TimeShift Fast-Forward – files, TimeShift Rewind – Files, TimeShift Snapshot (capture single image) Record TV Minimize to taskbar End program Enable/Disable TimeShift Play files Open function setting window Open EPG window Open My Favorite...
- Page 14 LCD display Display volume Mute on/off Display playing status Display RF strength Display RF quality Display media type Display channel Display TimeShift playing time Display playing speed Display file name or name of external device A time scroll will appear after TimeShift is activated. Red represents the recorded sections and green represents sections available for recording.
-
Page 15: Functional Setting
Functional setting 3.3.1 General Full screenÆ Activate full screen playing Always on Top Æ Fix the image display window on top of the desktop Enable OSD Æ Turn on OSD display Refresh RD Information Æ Turn on RF information display... - Page 16 3.3.2 Scan channel RF frequency Æ There are 4 modes available for selection: “Country/Region”, “All”, “Range”, and “Single”. Bandwidth Æ There are 3 types of bandwidth available for selection: “6”, “7”, and “8” Start Æ Start scanning Stop Æ Stop scanning Scan process Æ...
- Page 17 3.3.3 Recorder Storage Resource Æ Display computer’s memory size Save To Æ Set recording path Progress Æ Display recording progress Enable Preset Æ Activate pre-schedule recording function Delete All Æ Delete all pre-schedule programs Delete Æ Delete a pre-schedule program Note: Once recording is completed, the “OK”...
- Page 18 3.3.4 Display Brightness Æ Adjust image brightness Contrast Æ Adjust image contrast Hues Æ Adjust image hues Saturation Æ Adjust image saturation Reset Æ Restore to default settings...
- Page 19 3.3.5 Capture Set image capture to Clipboard or an assigned folder 3.3.6 TimeShift Set time limit for TimeShift.
-
Page 20: Right Click Menu
Right click menu The following functions will appear when right clicking on the control panel or TV broadcasting window. -
Page 21: Chapter 4 Trouble Shooting
“Sound, video and game controllers”, there must be a device named “DVB-T USB2.0/1.1 adapter”. If not, please remove the USB box, plug it into the USB port again and follow the steps in “Chapter 2. Installation procedure” in the user manual to re-install the driver. - Page 22 6. When error dialog box pops up or black screen appears Might be resulted from poor signal quality, DVB-USB doesn't receive enough data of program or receives wrong data. Please check the connection between DVB-T USB SET-TOP BOX and the antenna.
