Transcend 2.5" 40GB StoreJetTM TS40GSJ25 Specifications

T S 4 0 G S J
T S 4 0 G S J
T S 4 0 G S J
Description
TS40GSJ25 is the Transcend StoreJet™ installing 2.5"
40GB hard disk. This device is designed to expedite
exchanging huge amounts of data between Transcend
StoreJet™ and any desktop or notebook computer.
Transcend also provides StoreJet Software including
StoreJet Utility (PC Lock and others under Device
Desktop) and ExBoot Express for Micorsoft Windows
OS users.
Placement
B
A
Transcend Information Inc.
2 5
2 5
2 5
C

System Requirements

• Desktop or notebook computers with USB port
• One of following operating systems:
Win 98/98SE, Win ME, Win 2000, Win XP,
Mac OS 9.0 or above
Features
• Fully compliant with USB 2.0 specification
• Fully backward compatible with USB 1.1 specification
• 100% compatible with USB interface in Windows or Mac
• High transfer rate up to 480 Mbits per second
• Easy plug and play installation
• Powered by USB bus power (DC 5V)
• LEDs indicate power on and data access
• Support 2.5" hard disk drive (Height: 9.5mm)
• High storage capacity: supports up to 80GB HDD
• Recommended operating temperature: 5 C ~ 55 C
• Connector durability: 5000 times
Dimensions
Side Millimeters
145.00 ± 1.00
A
80.00 ± 1.00
B
17.00 ± 1.00
C
1
2.5" 40GB StoreJet
° °
Inches
5.71± 0.04
3.15 ± 0.04
0.67 ± 0.04
™
