TS2G/4GMP615
Description
TS2G/4GMP615 is a 2GB/4GB USB
Flash Drive with 1 pcs of 2Gx8/4Gx8x8
Flash Memory assembled on the printed
circuit board. It combines a USB Flash
Drive with an MP3 player, AB repeater,
voice recorder and an FM radio.
Outline
A
Hi-Speed mini USB 2.0 Connector
B
Microphone
C
Dual-Color OLED Display
D
E
F
G
H
I
J
Lanyard Attachment Loop
K
L
M
N
O
Features
MP3 Player – supports MP3, WMA,
WMA-DRM10 (subscription music) and
WAV music formats
Recordable FM Radio with 20 station
presets
Advanced Digital Voice Recorder
Karaoke-style lyrics display
Vivid dual-color OLED screen displays
clear text at any angle and in any light
VAD (Voice Activity Detection) for high
quality gapless audio recordings
A-B repeat function allows you to
continuously replay a designated section
of a track
Play / Pause / Power
Volume Up
Previous / Rewind
Volume Down
Next / Fast-Forward
Headphone Jack
Hold Switch
Record
Menu Button
A-B Repeat
Reset Button
Advertisement
Related Manuals for Transcend TS2G/4GMP615
Summary of Contents for Transcend TS2G/4GMP615
- Page 1 TS2G/4GMP615 Description TS2G/4GMP615 is a 2GB/4GB USB Flash Drive with 1 pcs of 2Gx8/4Gx8x8 Flash Memory assembled on the printed circuit board. It combines a USB Flash Drive with an MP3 player, AB repeater, voice recorder and an FM radio.
- Page 2 Variable track playback speeds Supports 13 languages menus, song/album title, artist name and lyrics USB flash drive capabilities for data transfer and storage Included software can be used to lock your computer and password-protect your files Equalizer effects, Block Diagram With 1 pcs of 2G/4G x8 Flash Memory Microphone customizable USER EQ setting...
- Page 3 Pinouts Pin No. Pin Identification Symbol USB+ USB- Pin Name USB- USB+ Function USB differential signal: The pairs are used to transmit Data/Address/Command USB Power Input Ground Ground...
-
Page 4: Specifications
Size (L x W x H): Weight: Music Formats: Recording Format: Estimated Battery Life: Compression Rates: Data Retention: Erase Cycles: Signal-to-Noise Ratio: Power Supply Certificates: Warranty: Specifications 70mm × 34.5mm × 15.5mm 28g (with Li-ion battery) MP3 WMA and WMA-DRM10 (Subscription music) ADPCM (WAV) 15 hours Music playback (fully charged battery)
