AD5900-15
15dB 5.8GHz Circular Polarized Patch Antenna
! Sturdy flat-panel design.
! Allows one-mile range when
used on the Tx and Rx of a
FalconPlus system.
! Transmitter and receiver versions
available.
! Circular polarized for the best
propagation in weather.
! Right-hand and left-hand circular
polarizations available.
! Designed for use with FalconPlus™
transmitters and receivers (as
shown, sold separately).
! Weatherproof.
! Cables and mounting hardware
included.
DATASHEET
™
Advertisement
Related Manuals for Trango Systems Circular Polarized Patch Antenna AD5900-15-R
Summary of Contents for Trango Systems Circular Polarized Patch Antenna AD5900-15-R
- Page 1 AD5900-15 15dB 5.8GHz Circular Polarized Patch Antenna ! Sturdy flat-panel design. ! Allows one-mile range when used on the Tx and Rx of a FalconPlus system. ! Transmitter and receiver versions available. ! Circular polarized for the best propagation in weather. ! Right-hand and left-hand circular polarizations available.
- Page 2 AD5900-15 AD5900-15 Electrical Properties FREQUENCY RANGE 5725–5875 MHz BANDWIDTH 150MHz (VSWR < 2.0:1) ELEMENT GAIN 15dBi FRONT-TO-BACK RATIO > 15dB AXIAL RATIO < 3dB across band E-PLANE BEAMWIDTH > 18° H-PLANE BEAMWIDTH > 18° POLARIZATION right-hand circular (-R), left-hand circular (-L) IMPEDANCE 50 Ohms nominal +1 858-653-3900 •...
