Technical Specifications
Freq. Range
Beamwidth
(MHz)
2400 - 2484
Gain (dBi)
24
Feedhorn
Dipole
Powdercoat white
Dimensions
Connector
23.5" x 15" x 39.5"
TNC to SMA on a
(assembled)
Mounting
Provisions
Pole up to 2 3/8",
hardware included
For more information contact:
Trango Systems
9939 Via Pasar · San Diego, CA 92126
Phone: (858) 653-3900 • Fax: (858) 621-2725
Copyright © 1997-99 Trango Systems. All rights reserved.
Features
· 24dB linear patch antenna
· 2400-2484 MHz
· Beamwidth: 10-13º
· Polarization: linear
10-13º
VSWR
1.5:1 (50 )
Finish
24" cable
Weight
5.5 lb
24dB Parabolic Grid
Features
Made in the USA. All specifications
subject to change without notice.
AD2401-24
Antenna
