Trango Systems 8-dB Yagi Antenna AD900-8Y-RP Technical Specifications

Frequency Range
Gain
-3dB Beamwidth H-Plane
-3dB Beamwidth E-Plane
Front-to-Back Ratio
Polarization
Rated Wind Velocity
Length
Weight
Connectors
Mounting Hardware Included U-bolts, fit up to 2-3/8" pipe
All specifications subject to change without notice.
For more information contact:
Trango Systems, Inc.
15070 Avenue of Science, Suite 200, San Diego, CA 92128
Phone: (858) 653-3900 • Fax: (858) 621-2725
sales@trangosys.com • www.trangosys.com
Features
• All-welded unit construction
• Waterproof design
• Extruded Aluminum with
White UV Polymer finish
• 3 Element Yagi
• 50 Ohm Impedance
Technical Specifications
900-928 MHz
8 dBi
90°
70°
15 dB
Vertical/Horizontal
150 MPH
15"
< 2 lbs.
Reverse polarity SMA-F
AD900-8Y-RP
8 dB Yagi Antenna
Rev B
