Summary of Contents for TP-Link TR-966D
- Page 1 User's Guide TR-966D 10/100Mbps WDM Fiber Bridge...
- Page 2 No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd. Copyright @2006 TP- LINK Technologies Co., Ltd. All rights reserved. Package Contents...1 Introduction...1...
-
Page 3: Package Contents
This User’s Guide Warranty card Introduction The TR-966D product is 10/100Mbps WDM Fiber Bridge. By deploying WDM technology (Wavelength Division Multiplexer), only single-mode fiber is needed to transmit and receive optical Ethernet packets. The TR-966D mediates between a 10/100Base-TX segment and a 100Base-FX segment. - Page 4 TR-966D 10/100M Fiber Bridge TR-966D Front Panel 2. Rear Panel The rear panel of the TR-966D consists of one AC power connector, two 10/100Mbps RJ45 ports and two SC Fiber interfaces. POWER TR-966D Rear Panel 3. LED Indicators This TR-966D has LED indicators which can provide a real- time report.
-
Page 5: Installation Guide
100 meters. Connect one end of twisted pair cable to RJ45 jack on the TR-966D and the other end of the cable to the cable to the RJ-45 jack on the 10/100Base-TX device. Connect the TR-966D to 100Base-FX Device Connection. -
Page 6: Appendix Specification
Single-mode fiber cable: 20km Environmental and Physical Power Power Adapter (9V, 0.8A) Dimension(LxWxH) 122mmx76mmx24mm Environment Operating temperature: 0ºC ~ 40ºC Storage temperature: -20ºC ~ 70ºC Humidity: 5% ~ 90% RH TP-LINK TECHNOLOGIES CO.,LTD. E-mail:support@tp-link.com Website:http://www.tp-link.com Add:3/F.,Buiding R1-B,Hi-tech Industrial Park,Shennan Rd.,Shenzhen,P.R.China...
