Tote Vision LCD-840D Specification Sheet

The Biggest Thing in
Little PC Capable
LCD Monitors
LCD-840D
Rack Mount Unit
Active Matrix 8.4" LCD Monitors with PC Capability
• Wireless remote control
• Composite, S-Video, and PC capability
• For color and B/W applications
• Active matrix technology allows wide viewing angle
• Acitve matrix technology eliminates distortion
• A/C adaptor included
• Response Time: 20ms/30ms (rising/falling)
• Built-in interface for wall or arm mounting
VESA 75mm FPMPMI compliant
LCD- 840VL 8.4" Unit in Flush Mount Kit
Dimensions (WHD): 290 x 213 x 40.6mm / 11.4" x 8.4" x 1.6"
Installer's Cut-out (WH): 229 x 175mm / 9" x 6.9"
Weight: Net: Est. 1.8 kg. / 4 lbs. Gross: Est. 2.7 kg. / 6 lbs.

Optional Accessories

MB-3 Desk stand (shown above)
HM-400 Under-cabinet hinge mount
Touchscreen: For 8.4" order LCD-840TS
Specifications subject to change without notice
Available through:
P.21
Actual visible screen size (WH):
©2008 ToteVision 30K
In Metal Case
LCD-840VL
Flush Mount Unit
Display: 8.4" TFT LCD active matrix
Input Signal: NTSC/PAL(auto sensing), S-Video, Analog RGB
Resolution: 800(H) x 600(V) dots
Brightness rating: 150 cd/m²(Nit)
Contrast Ratio: 200:1LCD-840 series: 45/45/35/15
55/55/35/15
Viewing angle L/R/T/B:
Power Requirements: Regulated 12 VDC, 3A (LCD-641V: Regulated 12 VDC, 2A)
Power Consumption: 30 W (max)
Video Input Level: 1.0 V P-P (positive) 75 Ohm
Dimensions (WHD): LCD-840D: 19" x 7" (Occupies 4 RU) x 1.75"
LCD-840V: 264 x 163 x 38mm / 10.4" x 6.4" x 1.5"
174 x 131mm / 6.9" x 5.2"
Operating temperature: 50 ~ 104°F or 10 ~ 40°C
Connections: RCA video IN, S-Video,
BNC video IN/OUT,
2.1 DC IN jacks,
15-pin mini D-sub (female)
Weight: LCD-840D: Net: 2.5 kg. / 5.6 lbs. Gross: 5.4 kg. / 12 lbs.
LCD-840V: Net: 3.2 kg. / 5.4 lbs. Gross: 3.6 kg. / 8 lbs.
LCD-840VL: Net: Est. 2.9 kg. / 6.4 lbs. Gross: 4.1 kg. / 9 lbs.
1319 Dexter Ave. N. • Ste. 020 • Seattle, WA 98109
Tel: 206-623-6000 • FAX: 206-623-6609
Email: sales@totevision.com
http://www.totevision.com
LCD-840D
LCD-840V
LCD-840VL
Shown with
optional MB-3
desk stand
